X20CP1485 B&R Input module

Product  Description：

The X20CP1485 is a standard CPU module that combines a powerful Intel Celeron processor with extensive communication interfaces. It is characterized by its fanless design, which enhances reliability in industrial environments by eliminating moving parts. This CPU is particularly effective for applications involving complex floating-point operations and high-speed data processing. Unlike the larger X20CP3485, the X20CP1485 features a slimmer width and one modular interface slot, making it ideal for space-constrained control cabinets without sacrificing core performance.

Product Parameters

• Processor: Intel Celeron 400 MHz equivalent performance.

• Memory: 32 MB DDR SDRAM (The X20CP1485-1 variant offers 64 MB).

• Retentive Memory: 1 MB SRAM for remanent variables.

• Onboard Interfaces:

  • 1x Ethernet (10/100 Base-T) for general networking and commissioning.

  • 1x POWERLINK (V1/V2) for hard real-time industrial communication.

  • 1x RS232 interface for serial communication.

  • 2x USB 2.0 interfaces for external storage or peripherals.

  • 1x X2X Link for connecting local and remote I/O modules.

• Expansion Slots: 1 slot for modular X20 interface cards (e.g., CAN, Profibus, RS485).

• Application Memory: Removable CompactFlash card (must be ordered separately).

• Supply Voltage: 24 VDC (-15% / +20%).

• Power Consumption: Approximately 7 Watts for the CPU/X2X Link supply.

• Environmental Protection: IP20 rating.

• Operating Temperature: Horizontal mounting from -25°C to +60°C.

Product Advantages

• High Real-Time Performance: Integrated POWERLINK ensures deterministic communication with cycle times as low as 400 µs, essential for motion control and synchronized processes.

• Compact Design: The module's narrow width allows for a higher density of components on the DIN rail, reducing the overall footprint of the control system.

• Maintenance-Free: The fanless architecture and lack of internal batteries (when used with appropriate memory cards) reduce the need for routine maintenance and increase the Mean Time Between Failures (MTBF).

• Flexibility: Despite its compact size, the single interface slot allows users to add specific fieldbus protocols or additional communication ports as needed.

• Background I/O Processing: An integrated I/O processor manages data points in the background, ensuring the main CPU can focus on the application logic and complex calculations.

Important Considerations (Precautions)

• Application Memory: The module does not include internal application storage; you must install a compatible CompactFlash card before the CPU can boot or store programs.

• Mounting Orientation: For optimal cooling, horizontal mounting is recommended. If mounted vertically, a temperature derating must be applied (typically limited to 50°C ambient).

• Power Supply and Fusing: Ensure the 24 VDC supply is stable. A maximum 10 A slow-blow fuse is required for the I/O power supply line to protect the module and connected I/O.

• Battery Maintenance: While the CPU is generally maintenance-free, if a backup battery is used for the real-time clock, it should be checked periodically or replaced if the diagnostic LEDs indicate a low battery state.

• Firmware Compatibility: Ensure that the Automation Studio software version used for programming is compatible with the hardware revision of the X20CP1485 to avoid communication errors.
