WSRDW63542  EATON Power Board

Product  Description：

An EATON Power Board, or panelboard, is an enclosure containing protective devices such as circuit breakers or fuses, bus bars, and sometimes metering and control components. Its primary function is to receive electrical power from a central source (like a switchboard or transformer) and safely distribute it to various loads within a commercial, industrial, or residential building.

EATON offers different types of panelboards, including:

• Lighting and Appliance Panelboards (e.g., Pow-R-Line 1a/2a): Used for circuits feeding lighting and convenience outlets, typically up to 600 A and 240 Vac.

• Power Distribution Panelboards (e.g., Pow-R-Line 3e/4X): Used for feeding power to larger motor loads, HVAC equipment, and other sub-distribution equipment, with higher voltage and interrupting ratings.

• Specialty/Hazardous Area Panelboards: Designed for use in environments with flammable gases or dusts, often with explosion-proof or factory-sealed construction.

The board houses the main overcurrent protection device (main breaker or lugs) and numerous branch circuit breakers that protect individual circuits from overloads and short circuits.

Product Parameters

The specific parameters depend on the product series (e.g., Pow-R-Line) but generally include:

• Maximum Voltage Rating: Ranging typically from $240 \text{ Vac}$ up to $600 \text{ Vac}$.

• Continuous Current Rating (Amperage): Often $100 \text{ A}$ to $1200 \text{ A}$ for distribution panelboards.

• Interrupting Rating (AIC): The maximum fault current the device can safely interrupt, ranging from $10 \text{ kAIC}$ to $200 \text{ kAIC}$ (kilo-amperes interrupting capacity), which is crucial for system protection.

• Bus Bar Material: Available in Aluminum or Copper.

• Enclosure Type: Various NEMA ratings (e.g., NEMA 1 for indoor, NEMA 3R for outdoor) and IEC/IP ratings, defining protection against environmental factors like dust and moisture.

• Mounting: Options for Surface or Flush mounting.

• Number of Circuits/Ways: Can accommodate up to 84 or more branch circuit devices.

Product Advantages

EATON Power Boards provide high safety and reliability through robust design and compliance with rigorous standards (e.g., UL, NEMA, IEC), ensuring superior circuit protection. They offer significant flexibility and scalability with modular designs, allowing for easy expansion and reconfiguration of branch circuits. Many models feature integrated solutions such as built-in surge protection devices (SPDs) and metering capabilities, which save space and simplify installation. EATON's designs often prioritize ease of installation and maintenance, incorporating features like tool-less trim installation and clear bus bar configurations to reduce labor time and improve safety for technicians.

Important Considerations (Precautions)

When working with or installing EATON Power Boards:

• Adhere to all local electrical codes (NEC, IEC, etc.) and manufacturer guidelines for installation, wiring, and grounding.

• Confirm the panelboard's Interrupting Rating (AIC) is equal to or greater than the maximum available fault current at the point of installation to ensure safe interruption of short circuits.

• Ensure the ambient temperature and environmental conditions are suitable for the specified NEMA/IP rating of the enclosure to prevent overheating or component damage.

• Properly torque all bus bar and terminal connections to the manufacturer's specification to prevent loose connections, which can lead to high resistance, heat, and potential fire hazards.

• Always de-energize and lock out/tag out the system before performing any internal inspection, maintenance, or modifications.

Product Applications

EATON Power Boards are essential components in all non-residential and larger residential electrical systems:

• Commercial Buildings: Distributing power for lighting, HVAC, elevators, and office equipment in high-rise buildings, schools, and retail centers.

• Industrial Facilities: Providing power distribution and circuit protection for machinery, motor control centers (MCCs), and factory lighting.

• Data Centers: Often using specialized panelboards for high-density, reliable distribution to IT equipment, sometimes including integrated monitoring.

• Healthcare Facilities: Ensuring reliable and safe power distribution to critical systems, often requiring high reliability and selective coordination.

• Residential Complexes: Serving as the main distribution point (load center or final distribution board) to feed household circuits.
