TM21001045-1SN Yokogawa

TM21001045-1SN Yokogawa Operator unit

Product  Description：

Yokogawa Operator Units, often referred to as Human-Machine Interfaces (HMIs) or Operator Interfaces, are specialized industrial terminals designed to facilitate seamless interaction between human operators and automated control systems, such as the CENTUM Distributed Control System (DCS) or STARDOM controllers. These units process complex system data into clear, actionable visual graphics, enabling operators to monitor plant conditions, adjust process variables, and respond to alarms in real time.

Product Parameters

The technical profile of a Yokogawa Operator Unit focuses on robust visualization capabilities and industrial-grade hardware reliability:

• Display Characteristics: High-resolution TFT color LCD screens available in various sizes, typically ranging from 5.7 inches up to 15 inches or larger, featuring wide viewing angles.

• Touch Panel Technology: Equipped with highly durable resistive or capacitive touch screens designed to operate reliably even when touched by operators wearing industrial gloves.

• Processor and Memory: Built with high-speed, low-power industrial processors paired with dedicated flash memory for storing complex graphics, alarm logs, and trend data.

• Interfaces and Connectivity: Features multiple communication ports including dual Ethernet ports for network redundancy, RS-232C, RS-422/485 serial ports, and USB ports for data backup and peripherals.

• Input Voltage: Designed to operate on standard industrial power supplies, typically requiring 24V DC or 100V to 240V AC depending on the specific model.

• Environmental Protection: Front panel configurations generally meet IP65F or NEMA 4X standards, offering high resistance to water splashes, dust, and oil mist.

Product Advantages

Yokogawa Operator Units are highly regarded in the process automation industry due to their specific operational benefits:

• Seamless DCS Integration: These units connect natively with Yokogawa's control systems, allowing direct access to controller registers without the need for complex third-party protocol conversions.

• High Availability and Redundancy: Many models support dual-network architecture, ensuring continuous operation and visibility even if one communication line fails.

• Advanced Alarm Management: Features an intuitive alarm summary display that categorizes alerts by priority, helping operators identify critical system faults instantly and reduce response times.

• Long-Term Reliability: Built with industrial-grade components that lack internal moving parts like cooling fans or rotating hard drives, significantly reducing the risk of mechanical failure.

• Ergonomic Graphic Design: Supported by comprehensive configuration software that allows for the creation of high-density, intuitive graphic displays based on modern ISA-101 human interface standards.

Product Applications

These operator terminals are deployed as primary interface points across heavy process industries worldwide:

• Oil and Gas Refining: Used in control rooms and field cabins to monitor distillation columns, pipeline pressures, and storage tank levels.

• Chemical and Petrochemical: Managing complex batch processing recipes, temperature profiles, and safety interlocks in hazardous manufacturing environments.

• Power Generation: Providing critical visualization for boiler controls, turbine parameters, and electrical distribution systems in utility plants.

• Water and Wastewater Treatment: Monitoring distributed pumping stations, filtration systems, and chemical dosing levels across municipal networks.

• Pharmaceutical Production: Interfacing with validated control systems to monitor environmental chambers, bioreactors, and cleanroom variables.

Important Precautions

To ensure safe operation and prevent hardware damage, the following precautions must be observed during installation and maintenance:

• Enclosure Grounding: The unit must be connected to a dedicated protective earth ground. Improper grounding can lead to erratic touch screen behavior and susceptibility to electrical noise.

• Chemical Exposure: While the front panel is highly resistant to dust and water, avoid exposing the screen to strong chemical solvents, acids, or abrasive cleaning agents which can degrade the touch surface.

• Explosive Atmospheres: When installing the unit in hazardous areas, ensure the specific model holds the appropriate explosion-proof certifications (such as ATEX or IECEx) and is installed using approved conduit seals.

• Panel Cutout Precision: During installation, ensure the panel cutout matches the manufacturer's exact dimensions. An uneven or overly tight cutout can warp the chassis and compromise the IP65 waterproof seal.

• Power Cycling: Wait at least ten seconds after turning off the power supply before turning it back on. Rapid power cycling can cause initialization errors in the internal storage or corruption of the firmware.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
