SCXI-1326 National Instruments

SCXI-1326  National Instruments Programmable controller

Product  Description：

The SCXI-1326 is a specialized terminal block that plugs directly into the front of the SCXI-1126 module. It features screw terminals for the connection of up to eight channels of input signals. Each channel includes terminals for signal positive, signal negative, and an optional shield. The terminal block is housed in a rugged enclosure that provides strain relief for the connected wires and ensures that high-voltage signals are contained safely away from the operator. It also includes an onboard cold-junction compensation (CJC) sensor, although its primary pairing with the SCXI-1126 (a frequency module) makes the CJC more relevant when used in other compatible SCXI configurations.

Product Parameters

• Input Channels: 8 differential channels.

• Voltage Rating: Supports signals up to $300 \text{ V}$ (Category II), making it suitable for high-voltage industrial sensing.

• Terminal Type: Screw terminals for secure, long-term wire retention.

• Wire Gauge: Typically accepts $16$ to $26 \text{ AWG}$ wire.

• Cold-Junction Compensation: Integrated thermistor for temperature-referenced measurements.

• Safety Isolation: Designed to meet high-voltage safety standards when used within a properly grounded SCXI chassis.

• Mechanical Connection: Direct-mount to the front of SCXI modules with thumb screws for tool-free installation and removal.

Product Advantages

One of the primary advantages of the SCXI-1326 is its High-Voltage Capability, allowing users to safely measure signals that would damage standard low-voltage data acquisition hardware. The Integrated Strain Relief is a significant mechanical benefit; it prevents accidental wire pull-outs and protects the terminal connections from mechanical stress.

Another advantage is the Shielding and Noise Reduction. The terminal block is designed to minimize electromagnetic interference (EMI), which is crucial when measuring frequency signals that are susceptible to noise-induced errors. Additionally, the Ease of Connectivity offered by the screw terminals allows for quick field wiring without the need for specialized crimping tools or custom cables.

Important Considerations and Precautions

When utilizing the SCXI-1326, the most critical precaution is Electrical Safety. Because this block can handle up to $300 \text{ V}$, it is vital to ensure the SCXI chassis is properly grounded and that all wiring is de-energized before making or breaking connections. Insulation Checks should be performed on all field wiring to prevent short circuits between high-voltage channels.

Users must also be aware of Signal Compatibility; while the block is rated for high voltage, the specific SCXI module it is attached to (such as the SCXI-1126) has its own input limits that must not be exceeded. Furthermore, ensure that the Terminal Screws are Tightened to the appropriate torque; loose connections can lead to signal loss or, in high-voltage scenarios, dangerous electrical arcing. Finally, always use the Strain Relief Bar included with the block to secure the cable bundle, as the weight of hanging wires can eventually damage the internal connectors.

Product Applications

The SCXI-1326 is widely used in industrial and laboratory settings where frequency and high-voltage signals must be conditioned and digitized.

• Power Generation: Monitoring the frequency of large turbines and generators where voltage levels can be high and signal stability is critical.

• Automotive Testing: Measuring engine RPM from ignition systems or variable-speed sensors during dynamometer testing.

• Industrial Flow Control: Interfacing with flow meters that output high-voltage pulse trains or frequency-encoded data.

• Material Testing: Used in setups where high-voltage sensors are employed to measure mechanical stress or rotational speed in harsh environments.

• Grid Monitoring: Collecting frequency data from power distribution systems for stability analysis and load balancing.
