NGH312032E EATON

NGH312032E EATON Basis unit

Product  Description：

The EATON Basis Unit, or Baseplate, is the foundational hardware component that physically holds and electrically connects various functional modules (CPU, I/O, communication) of an industrial control system. It incorporates the system bus, which is a high-speed backplane for data exchange and power distribution among the installed modules. Its robust design ensures reliable performance in industrial environments.

Key Functions

• Mechanical Mounting: Provides a secure physical structure for mounting all expansion and control modules.

• Bus Communication: Houses the system backplane bus (e.g., XN300 bus), facilitating high-speed data transfer between the CPU and I/O modules.

• Power Distribution: Distributes the necessary operating power from the power supply module to all connected modules.

• System Expansion: Defines the number of slots available for system growth, allowing users to tailor the system capacity to application needs.

Product Parameters (Typical)

Parameters are highly dependent on the specific product family (e.g., modular PLC systems).

• Number of Slots: Defines the system capacity (e.g., 2, 4, 8, or 12 module slots).

• Bus Speed: The internal data transfer rate of the backplane bus (specific Mbit/s depending on the series).

• Power Capacity: The maximum current (Amps) the baseplate's bus can handle and distribute to the modules.

• Dimensions: Physical size, height, width, and depth, specified for standard enclosure mounting (e.g., DIN rail mountable).

• Mounting Type: Typically designed for DIN rail mounting (35 mm).

• Operating Temperature: Standard industrial range (e.g., 0°C to +55°C).

• Isolation: Electrical isolation between power, ground, and communication lines.

Product Advantages

• Modularity and Flexibility: Allows for a highly customizable control system configuration, enabling users to add or change modules easily.

• Scalability: The availability of different slot counts allows the system to scale from small to large-scale applications without changing the core platform.

• High Reliability: Features a rugged design with high-quality connectors to ensure dependable module communication and connection stability in harsh industrial settings.

• Simplified Wiring: Centralized power and communication reduce complex external wiring between modules, simplifying installation and maintenance.

• System Integration: Provides a unified, high-speed backbone for EATON's control components, ensuring optimal system performance.

Precautions

• Compatibility: Always ensure the Basis Unit is compatible with the specific EATON PLC family (e.g., XN300) and the modules being installed.

• Module Insertion: Insert and remove modules carefully to prevent damage to the backplane connectors and the internal bus.

• Slot Placement: Follow the system's design rules regarding slot placement, particularly for the CPU and power supply modules, which typically require designated slots.

• Power Budget: Ensure the total current drawn by all installed modules does not exceed the power capacity of the Basis Unit and the connected power supply module.

• ESD Protection: Handle the unit and modules using proper electrostatic discharge (ESD) precautions during installation.

Product Applications

EATON Basis Units are used as the core structure for modular control systems across diverse industrial sectors.

• Factory Automation: Controlling and monitoring complex machinery, production lines, and robotics.

• Building Automation: Managing large-scale HVAC, lighting, and access control systems.

• Machine Control: Serving as the foundation for control systems in packaging machines, conveying systems, and machine tools.

• Water and Wastewater: Housing the controllers that manage pump stations, filtration, and process monitoring.

• Power Distribution Control: Used within electrical distribution centers for control and monitoring applications.
