MVI56-104S PROSOFT

MVI56-104S PROSOFT Multi-Function Processor Module

Product  Description：

The ProSoft Technology MVI56-104S is a Serial Communications Interface Module designed for the Rockwell Automation ControlLogix platform. This module provides a flexible solution for integrating various serial devices, such as those using Modbus Serial, into the ControlLogix architecture.

Product Specifications

• Platform Compatibility: Single-slot, 1756 ControlLogix backplane compatible.

• Communication Ports: Features four independent, fully configurable serial communication ports.

• Serial Port Type: Each port is software-configurable for RS-232, RS-422, or RS-485 standards via an external port adapter.

• Isolation: Provides 500V optical isolation from the backplane.

• Data Rates (Baud): Supports baud rates up to 115.2 kbps.

• Protocol Support: Primarily designed to support Modbus Master/Slave over serial (RTU/ASCII) but can often be configured for other serial protocols like DF1 or Generic ASCII.

• Data Format: The module uses a block of memory (data files) that are mapped to the ControlLogix processor's memory, allowing for easy data transfer using typical ControlLogix messaging.

• Backplane Current Load: Typically $800 \text{ mA}$ at $5 \text{ VDC}$ and $3 \text{ mA}$ at $24 \text{ VDC}$.

• LED Indicators: Includes LEDs for Module Status (OK), Application Status (APP), and serial activity (RX/TX) for each port.

Product Advantages

• Four Independent Channels: The main advantage is the availability of four separate serial ports, allowing the module to interface with multiple, disparate serial networks or devices simultaneously, maximizing backplane space efficiency.

• Protocol Versatility: It supports the widely used Modbus Serial (RTU/ASCII) protocol, making it ideal for connecting to a large installed base of industrial devices (e.g., VFDs, flow meters, PLCs).

• Seamless ControlLogix Integration: It operates as a standard I/O module within the ControlLogix chassis, simplifying configuration and data handling via Studio 5000 and dedicated ProSoft Add-On Instructions (AOIs).

• Master/Slave Functionality: Ports can be independently configured as a Master (initiating communication) or a Slave (responding to requests), providing flexibility for system architecture.

Important Considerations (Precautions)

• Wiring Standards: Correctly adhere to the specific wiring standards (RS-232, RS-422, or RS-485) required by the external devices. Improper wiring, especially for RS-485 networks, can lead to communication failures.

• External Adapter: The module requires external port adapters to connect the physical field wiring. Ensure the correct adapter type is used for the desired serial standard (RS-232, 422, or 485).

• Configuration: The module requires careful configuration using ProSoft's dedicated configuration software to define the serial parameters (baud rate, parity, etc.) and the Modbus data mapping for each of the four ports.

• Discontinued Status: Like other MVI56 modules, the MVI56-104S is a discontinued/legacy product. It has been replaced by the MVI56E-MCM (Modbus Communication Module) or equivalent MVI56E series modules, which offer enhanced performance and diagnostics. New installations should consider the 'E' series.

Product Applications

The MVI56-104S module is typically deployed in industrial environments where data exchange with multiple serial devices is necessary within a ControlLogix control system.

• Power and Energy: Connecting to power monitors, protective relays, and other intelligent electronic devices (IEDs) using Modbus protocol.

• Water and Wastewater: Interfacing with remote terminal units (RTUs), well monitors, and flow controllers over serial lines.

• Oil and Gas: Integrating serial flow computers, tank gauging systems, and compressor controls.

• Factory Automation: Connecting multiple peripheral devices like barcode scanners, weigh scales, and older variable frequency drives (VFDs) that communicate via Modbus Serial or other asynchronous protocols.

The structure and details of the product：
