ISO685-S BENDER

ISO685-S BENDER Processor module

Product  Description：

Bender Processor Modules function as the central computational core within specialized electrical safety and monitoring systems. Manufactured by Bender, a leader in electrical safety technology, these modules are engineered to process high-resolution signals from current transformers and insulation monitoring devices. They execute advanced algorithms to calculate insulation resistance, residual currents, and power quality metrics, transmitting critical safety data to industrial networks and supervisory control systems.

Product Parameters

The technical composition of a Bender Processor Module is defined by its precision measurement capabilities and industrial network compliance:

• Processing Core: High-performance microcontroller capable of running continuous evaluation algorithms for insulation and residual current data.

• Supply Voltage Range: Versatile auxiliary power inputs, typically supporting 24V DC or a wide-range AC/DC supply from 100V to 240V.

• Measurement Sensitivity: Able to evaluate differential and residual currents ranging from microamperes up to several Amperes depending on the connected sensor.

• Response Delay Configuration: Adjustable response times, often configurable from 0 seconds to 10 seconds, to prevent nuisance tripping during transient system events.

• Communication Bus: Integrated industrial interfaces, primarily supporting Modbus RTU, Modbus TCP/IP, or proprietary Bender BMS (Bender Measuring Bus) protocols.

• Enclosure and Protection Class: Designed for standard DIN rail mounting, typically carrying an IP20 protection rating for internal panel installation.

Product Advantages

Bender Processor Modules provide distinct advantages in building-wide electrical safety and predictive maintenance architectures:

• Continuous System Visibility: Unlike standard circuit breakers that only trip during a hard fault, these modules provide real-time trending data of insulation degradation, allowing for proactive maintenance.

• Advanced Harmonic Filtering: Integrated digital filters allow the processor to accurately evaluate true RMS values while ignoring non-hazardous high-frequency noise generated by variable speed drives.

• Comprehensive Multi-Channel Monitoring: A single processor module can evaluate signals from multiple measuring channels simultaneously, reducing the overall hardware footprint in the control cabinet.

• Intelligent Warning Thresholds: Features two-stage alarm management, allowing operators to receive a "pre-warning" alert before the main alarm threshold is breached and the system trips.

• Seamless Digital Integration: Converts complex analog safety metrics into digital network registers, making it easy to map critical safety data into existing SCADA or building management systems.

Product Applications

These modules are critical components in industries where electrical uptime and human safety are paramount:

• Healthcare Facilities: Monitoring ungrounded power supplies (isolated IT systems) in operating rooms and intensive care units to detect insulation faults instantly.

• Data Centers and IT Infrastructure: Tracking residual currents in continuous-operation server halls to prevent unexpected power outages caused by ground faults.

• Renewable Energy Installations: Evaluating insulation resistance on the DC side of large-scale solar photovoltaic arrays and wind turbine generators.

• Maritime and Offshore Engineering: Managing the electrical safety networks of ships and offshore platforms where ungrounded electrical systems are heavily utilized.

• E-Mobility Charging Infrastructure: Integrated into high-power DC fast-charging stations to monitor the isolation barriers between the vehicle and the grid.

Important Precautions

To maintain precision and prevent operational hazards, the following installation and handling guidelines are required:

• Proper Sensor Matching: The module must only be used with compatible Bender measuring current transformers. Using third-party sensors will result in incorrect readings and compromise safety functions.

• Functional Earth Connection: Ensure that the dedicated functional earth terminal is connected directly to the central ground bus using a short, low-impedance wire to minimize electrical noise interference.

• Shielding Guidelines: Communication lines and sensor signal cables must be shielded. The shield should be grounded according to the system design manual to prevent ambient electromagnetic fields from altering measurement accuracy.

• Configuration Verification: Before putting the monitored system into service, verify that the alarm parameters, system voltage settings, and CT ratios are programmed correctly within the module software.

• Power-Isolation for Maintenance: Before performing insulation tests on the main power system using an external high-voltage megohmmeter, disconnect the processor module from the network to prevent high voltages from destroying the internal sensing circuitry.
