IR425-D4-2 BENDER

IR425-D4-2 BENDER Power module

Product  Description：

The IR425-D4-2 belongs to a family of insulation monitoring devices (IMDs) that utilize the patented AMP (Adaptive Measuring Pulse) measurement principle. This technology allows the device to adapt to the system leakage capacitance, ensuring accurate measurements even in networks with high interference or significant electronic components. It monitors the insulation resistance between the ungrounded system conductors and the equipment grounding conductor (PE). If the resistance falls below a pre-set response value, the device triggers an alarm through its integrated changeover relays.

Product Parameters

• Monitored System Voltage: Supports AC $0$ to $300 \text{ V}$ ($15$ to $460 \text{ Hz}$) and DC $0$ to $300 \text{ V}$.

• Supply Voltage (Us): AC $70$ to $276 \text{ V}$ ($45$ to $460 \text{ Hz}$) or DC $70$ to $276 \text{ V}$.

• Response Values: Two separately adjustable response values ($Ran1$ and $Ran2$) ranging from $1 \text{ k}\Omega$ to $200 \text{ k}\Omega$.

• System Leakage Capacitance (Ce): Maximum permissible system leakage capacitance is up to $20 \mu\text{F}$.

• Display: Digital LC display showing the current insulation resistance value and configuration parameters.

• Output Contacts: Two independent alarm relays with one changeover contact each (N/C or N/O operation selectable).

• Measuring Voltage (Um): $\pm 12 \text{ V}$.

• Measuring Current (Im): $\leq 200 \mu\text{A}$.

• Enclosure: DIN rail mounting (standard 35mm), $36 \text{ mm}$ width.

Product Advantages

One of the primary advantages of the IR425-D4-2 is its Universal Application Capability, as it handles both AC and DC systems effectively. The AMP Measurement Technology provides a high level of interference immunity, preventing nuisance alarms caused by system noise or harmonic distortion. Its Dual Alarm Levels allow for a "Pre-warning" and a "Main Alarm," giving operators time to address deteriorating insulation before a critical failure occurs. Furthermore, the Compact Design saves significant space in electrical cabinets, while the Self-Monitoring Feature ensures the device continuously checks its own connection to the system and the ground.

Important Considerations and Precautions

When installing the IR425-D4-2, ensure that only one insulation monitor is connected to a specific IT system; connecting multiple monitors can lead to measurement interference. Before performing high-voltage insulation tests on the monitored system, the IR425-D4-2 must be disconnected, as the test voltage may damage the internal electronics. It is also crucial to verify that the Supply Voltage (Us) stays within the $70-276 \text{ V}$ range to avoid device malfunction. Lastly, ensure that the connection to the PE (Ground) is solid and low-impedance, as the accuracy of the entire monitoring system relies on this reference point.

Product Applications

The IR425-D4-2 is ideal for small to medium-sized IT systems where reliability and safety are paramount.

• Control Circuits: Monitoring the insulation of $24 \text{ VDC}$ or $110/230 \text{ VAC}$ control circuits in industrial machinery to prevent unintended startups.

• Mobile Power Systems: Used in mobile generators and emergency power units where a ground fault could create a hazardous situation.

• Renewable Energy: Monitoring DC circuits in solar PV installations or battery storage systems.

• Shipbuilding and Marine: Protecting electrical systems on vessels where ungrounded networks are used to maintain operational continuity during a first ground fault.

• Medical Equipment: Used in specific non-critical medical power supplies to ensure patient and operator safety.
