DSMB-02C ABB Bailey

DSMB-02C ABB Bailey Analog Output Modules

Product  Description：

• • • • The ABB DSMB-02C is a Control Board or Control Driver Board primarily used within ABB's high-performance industrial drives, such as the ACS800 drive family, and potentially in older ABB Bailey Distributed Control Systems (DCS) or other industrial control applications. It acts as a central processing and interface unit for managing complex control algorithms, especially for motion and speed control.

        Product Specifications

        • Product Type: Control Board / Main Board / Controller Module

        • Manufacturer: ABB (Asea Brown Boveri)

        • Compatible Drive Family: Primarily associated with the ACS800 series of AC industrial drives.

        • Function: Serves as the main control unit, often incorporating a high-speed microprocessor and advanced algorithms to manage motor control tasks, speed regulation, and system monitoring. In the context of the ACS800, it can also function as a Pulse Encoder Interface Module for providing speed and position feedback.

        • Weight (Approximate): Approximately $0.3 \text{ kg}$ to $0.5 \text{ kg}$

        • Operating Voltage: Some sources indicate compatibility with input voltage ranging from $90 \text{ VAC}$ to $264 \text{ VAC}$ (for the overall system/drive it is a part of). It typically operates from a low-voltage DC supply provided by the main drive unit.

        • Power Consumption (Approximate): Up to $20 \text{ W}$.

        • Protection Features: Includes built-in safeguards against common issues like overcurrent and overheating to protect both the board and connected equipment.

        • Diagnostics: Features LED indicators for system status and signal monitoring.

        Product Advantages

        • High Performance Control: The board uses a high-speed microprocessor and advanced control algorithms, ensuring the real-time processing and stability critical for demanding motion and speed control applications.

        • Precision and Reliability: Engineered for industrial environments, it offers meticulous and precise control capabilities, which are essential for maintaining accurate operation in industrial settings.

        • High Compatibility: When used as a drive spare, it ensures full compatibility and seamless integration with the corresponding ABB ACS800 drive family, simplifying maintenance and upgrades.

        • Versatile Connectivity: The design includes multiple input/output ports and interface options to connect with various sensors, actuators, and industrial communication buses.

        • Robust Design: Built with high-quality materials to ensure long-lasting durability and consistent performance in harsh industrial operating temperature ranges (typically $-20^{\circ}\text{C}$ to $+55^{\circ}\text{C}$).

        Important Considerations (Precautions)

        • Professional Installation: Due to its function as a critical control board, installation, commissioning, and replacement should only be performed by qualified personnel familiar with the specific ABB drive system and all relevant electrical safety procedures.

        • Power Isolation: Always ensure all power sources to the drive system are completely disconnected and locked out before handling, installing, or removing the control board to prevent electric shock and damage to the sensitive electronics.

        • Electrostatic Discharge (ESD): The board is sensitive to electrostatic discharge. Proper ESD precautions (such as grounding wrist straps and conductive work surfaces) must be used during handling and installation.

        • Firmware Compatibility: If replacing an existing board, ensure that the new DSMB-02C has the correct firmware or that the appropriate firmware can be loaded to match the specific application and parameters of the drive system.

        • Documentation: Refer to the specific user manual for the ABB drive (e.g., ACS800) for detailed wiring diagrams, configuration procedures, and precise torque specifications for any terminal connections.

        Product Applications

        The primary application for the DSMB-02C is as a key component within ABB industrial drives, where it provides the intelligence for motor control.

        • High-Performance Motor Control: Used in the ABB ACS800 AC drive series to control the speed and torque of AC motors in a highly precise manner.

        • Industrial Automation Projects: Applied in general industrial automation projects requiring a robust and reliable control solution for motion and process tasks.

        • Process Industries: Found in applications within industries like pulp and paper, metals, mining, and oil and gas, where precise motor and machine control is critical for production processes.

        • Upgrading and Maintenance: Serving as a spare part for maintenance and repair of existing ABB drive systems to restore functionality and reliability.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
