6AV3607-1JC20-0AX1  SIEMENS Basis unit

Product  Description：

The 6AV3607-1JC20-0AX1 is an Operator Panel OP7 in the "Advanced" or DP (Decentralized Peripherals) version. It features a high-contrast backlit LC display capable of showing text and simple graphics. Unlike modern touchscreens, it relies on a set of 22 system keys and 8 user-configurable function keys with integrated LEDs for input. The "DP" designation indicates its native capability to communicate over PROFIBUS DP networks at speeds up to $12 \text{ Mbit/s}$, making it an ideal companion for SIMATIC S7-300 and S400 controllers.

Product Parameters

• Display Type: Backlit LCD (Liquid Crystal Display)

• Resolution/Capacity: 4 lines of text with 20 characters per line; character height is approximately $11 \text{ mm}$

• Input Method: Tactile membrane keyboard with 30 keys total (8 function keys, 4 with LEDs)

• Supply Voltage: $24 \text{ VDC}$ (operational range from $18 \text{ VDC}$ to $30 \text{ VDC}$)

• Current Consumption: Approximately $0.23 \text{ A}$

• Memory: Integrated Flash/RAM for project data and recipe management

• Interfaces: 1 x RS-485 (Interface for PROFIBUS DP/MPI) and 1 x RS-232 (for programming or printer connection)

• Degree of Protection: IP65 on the front (when correctly installed with gasket) and IP20 on the rear

• Ambient Operating Temperature: $0\text{°C}$ to $50\text{°C}$

• Dimensions: Front plate size is $144 \text{ mm} \times 180 \text{ mm}$; mounting cutout is $135 \text{ mm} \times 171 \text{ mm}$

Product Advantages

A major advantage of the OP7-DP is its Industrial Ruggedness. The membrane keypad is designed for millions of actuations and is resistant to many industrial chemicals, oils, and dirt, which often plague touchscreens in harsh environments. Its High-Speed Communication via PROFIBUS DP ensures that process values are updated almost instantaneously, providing the operator with real-time feedback.

The Compact Depth of the unit allows it to be installed in shallow control cabinets or small operator stations where space is limited. Additionally, the Configurable Function Keys allow for "one-touch" operations, such as starting a motor or acknowledging an alarm, which significantly improves operator efficiency compared to navigating complex software menus.

Important Considerations and Precautions

When dealing with the 6AV3607-1JC20-0AX1, it is important to note that this product is now in its Legacy/Discontinued phase. Spare parts may be difficult to source, and modern programming software like TIA Portal does not support this hardware; it typically requires the older ProTool or WinCC Flexible (Standard/Advanced) software for configuration changes.

During installation, ensure the Front Gasket is properly seated to maintain the IP65 rating; failure to do so can allow moisture to seep into the cabinet and cause short circuits. Because the unit uses an LCD with a Backlight, the display brightness will naturally dim over many years of continuous use; if the screen is unreadable, it is usually the backlight tube nearing its end of life. Finally, always ensure the PROFIBUS Termination Resistor is correctly set at the end of the network segment to prevent communication errors that could stop the entire machine.

Product Applications

The Siemens OP7-DP was widely deployed across various sectors before being superseded by the Comfort and Basic panel lines.

• Plastic and Rubber Processing: Monitoring temperatures and pressures on extrusion lines and injection molding machines.

• Food and Beverage: Managing simple mixing processes, recipe selection, and reporting alarm statuses in bottling plants.

• Conveyor Systems: Serving as a local control station for manual/auto switching and status monitoring of long transport belts.

• Pump Stations: Providing a local interface for water pressure settings and pump runtime diagnostics in utility sheds.

• Machine Tooling: Simple metal-cutting or wood-processing machines where text-based instructions and durable buttons are preferred over complex graphics.
