2090-XNSM-T Allen-Bradley

2090-XNSM-T Allen-Bradley I / O module

Product  Description：

The 2090-XNSM-T is a 15-pin High-Density D-Shell (Sub-D) connector kit. Unlike pre-molded cables, this "T" suffix version (often referring to the Terminal or Solder type) allows technicians to custom-build or repair feedback cables in the field. It is engineered to provide a low-impedance path for feedback signals, which is vital for the precision timing required in closed-loop motion control systems. The kit typically includes the connector insert, the metal housing (backshell) for shielding, and the necessary mounting hardware.

Product Parameters

• Connector Type: 15-pin High-Density D-Subminiature.

• Connection Method: Solder-type terminals for manual wire attachment.

• Compatibility: Primarily designed for Kinetix 6000, Kinetix 6200, and Kinetix 6500 servo drives.

• Shielding: Metallic backshell designed for 360-degree EMI/RFI shielding effectiveness.

• Mounting Style: Drive-end connection (plugs into the I/O or feedback port of the servo drive).

• Material: Industrial-grade thermoplastic and metal construction for durability in vibrating environments.

• Orientation: Straight exit (typical for standard D-sub backshells in this series).

Product Advantages

• Field Customization: Because it is a solder-style kit, it allows for custom cable lengths, which is ideal for unique cabinet layouts where standard cable lengths would result in excessive slack or tension.

• Superior Signal Integrity: The heavy-duty metallic backshell provides excellent protection against Electromagnetic Interference (EMI), which is a common cause of "Feedback Loss" or "Encoder Error" faults in industrial environments.

• Cost-Effective Maintenance: Instead of replacing an entire expensive pre-molded cable if a connector is damaged, the 2090-XNSM-T allows for a targeted repair of the drive-end interface.

• Robust Mechanical Grip: The design includes cable strain relief features that prevent the internal solder joints from fatiguing or breaking due to machine vibration or cable movement.

Important Considerations

• Soldering Expertise Required: Since this is a solder-style connector, the reliability of the entire motion system depends on the quality of the solder joints. Cold solder joints or bridges between the high-density pins can lead to intermittent system failures or short circuits.

• Proper Shielding Termination: To maintain the EMI advantages, the cable shield must be correctly bonded to the metallic backshell of the connector. Failure to do so can result in signal noise affecting motor positioning.

• Pinout Accuracy: It is critical to follow the specific wiring diagram for the motor-drive combination being used. A mismatched pinout can permanently damage the encoder inside the servo motor or the feedback input on the Kinetix drive.

• Environment: While robust, this connector should be housed within an electrical cabinet. It does not provide high IP-rated liquid ingress protection (like IP67) on its own at the solder point.

Product Applications

The 2090-XNSM-T is used wherever Allen-Bradley Kinetix Servo Drives are deployed in high-precision motion control.

• Robotics and Kinematics: Connecting feedback from multi-axis robotic arms to the main control cabinet.

• Packaging Machinery: Used in high-speed pick-and-place or wrapping machines where precise motor position is required to sync with conveyors.

• CNC Machining: Interfacing spindle or axis motors with the drive system to ensure sub-millimeter accuracy.

• Automotive Assembly: Applied in automated welding and assembly lines where reliability and noise immunity are paramount due to the proximity of high-power equipment.

• Material Handling: Used in automated storage and retrieval systems (AS/RS) to ensure accurate positioning of lifts and shuttles.
