2090-XNSM-M Allen-Bradley

2090-XNSM-M Allen-Bradley I / O module

Product  Description：

The Allen-Bradley 2090-XNSM-M is a specialized Motor Feedback Connector Kit manufactured by Rockwell Automation. It is specifically designed for use with Kinetix 6000 and Kinetix 6200 multi-axis servo drives. This connector acts as the physical interface between the drive and the motor's feedback cable, ensuring that high-speed position and velocity data are transmitted accurately from the motor's encoder to the drive's control circuitry.

Product Specifications

• Product Type: Feedback Connector Kit

• Connector Style: Solder-style connector with a metal housing

• Compatibility: Exclusively designed for the Kinetix 6000, Kinetix 6200, and Kinetix 6500 servo drive families

• Connection Type: 15-pin High-Density D-Sub (Male)

• Housing Material: Ruggedized metal shell for industrial durability and electromagnetic shielding

• Weight: Approximately $0.05 \text{ kg}$ to $0.1 \text{ kg}$

• Mounting: Attaches to the I/O or Feedback port on the front of the Kinetix drive module

• Kit Components: Typically includes the 15-pin D-sub connector, the metal backshell/hood, and necessary mounting screws

Product Advantages

• High Signal Integrity: The metal shell provides superior shielding against Electromagnetic Interference (EMI), which is critical for maintaining precise feedback signals in electrically noisy industrial environments.

• Compact Design: Its low-profile architecture allows for dense mounting of multiple servo drives side-by-side in a ControlLogix or Kinetix rack without mechanical interference.

• Reliability: By using a high-density D-sub interface, the 2090-XNSM-M ensures a vibration-resistant connection, reducing the risk of "Feedback Loss" faults that can cause machine downtime.

• Ease of Identification: As a genuine Rockwell Automation accessory, it is designed for a perfect fit, eliminating the guesswork associated with third-party generic connectors.

Important Considerations and Precautions

• Wiring Precision: This is a solder-type connector. It requires high-quality soldering techniques to ensure no "cold" joints or bridges between pins, which could lead to intermittent feedback errors.

• Shielding Continuity: For optimal performance, the cable shield must be properly clamped to the metal backshell of the 2090-XNSM-M to provide a continuous $360^{\circ}$ ground path for noise.

• Avoid Hot-Swapping: Never connect or disconnect the feedback connector while the drive is powered. Doing so can cause electrical arcs that damage the sensitive encoder electronics inside the motor.

• Pin Alignment: Exercise care when plugging the connector into the drive. The high-density pins are relatively fragile and can be bent if the connector is forced at an incorrect angle.

• Environmental Limits: While the metal shell is robust, the connector itself is not waterproof. It must be installed inside a control cabinet that meets the appropriate IP rating (typically IP54 or higher) to prevent contamination.

Product Applications

The 2090-XNSM-M is utilized in any automation system employing Kinetix 6000 series drives for motion control. Common applications include:

• Packaging Machinery: Used in high-speed pick-and-place robots and wrapping machines where precise motor positioning is mandatory.

• Automotive Assembly: Applied in robotic welding and parts handling systems that require constant feedback for synchronized movement.

• Material Handling: Found in automated storage and retrieval systems (AS/RS) where servo motors control the X, Y, and Z axes.

• Food and Beverage: Employed in bottling and filling lines that use multi-axis synchronization to maintain high throughput and accuracy.

• Printing and Converting: Critical for maintaining web tension and registration where even a minor feedback lag can result in significant product waste.
