X20CP1486 B&R

X20CP1486 B&R Input module

Product  Description：

The X20CP1486 is an Intel Celeron-based processor module that integrates the CPU, memory, and various interfaces into a single unit. It serves as the "brain" of an X20 control system, managing local and remote I/O modules while executing complex control logic. It is designed to be mounted on a backplane bus and is fully integrated into the B&R Automation Studio engineering environment. The module features integrated Ethernet, USB, and POWERLINK interfaces, providing a versatile foundation for modern industrial networking.

Product Parameters

The technical profile of the X20CP1486 includes several high-end specifications tailored for industrial environments:

• Processor: Intel Celeron $400 \text{ MHz}$ processor.

• Memory: Equipped with $256 \text{ MB}$ DDR2 SDRAM and $512 \text{ kB}$ of retentive NVRAM for storing critical process data during power loss.

• Interfaces: Features one onboard Ethernet port (10/100 Mbit/s), one POWERLINK interface for real-time communication, and two USB 2.0 ports.

• Storage: Utilizes a CompactFlash slot for the operating system and user application software.

• Cycle Time: Capable of extremely short task cycles, reaching down to $400 \text{ \mu s}$ or less depending on the application complexity.

• Real-Time Clock: Integrated battery-backed clock for time-stamping and scheduling.

• Operating Voltage: $24 \text{ VDC}$ through the X20 system supply.

Product Advantages

One of the primary advantages of the X20CP1486 is its High Processing Power relative to its small physical footprint. By utilizing an Intel Celeron processor, it can handle complex mathematical calculations and high-speed motion control tasks that would overwhelm standard microcontrollers.

The Integration of Real-Time Ethernet (POWERLINK) allows for perfectly synchronized communication with drives and I/O, ensuring deterministic behavior in time-critical applications. Additionally, the Modular Design of the X20 system means this CPU can be easily expanded with specialized communication modules (like CANopen, Profibus, or DeviceNet) and a wide array of I/O slices. The Fanless Operation enhances reliability by removing a common mechanical point of failure, making it suitable for maintenance-free operation in industrial cabinets.

Important Considerations and Precautions

When working with the X20CP1486, several technical precautions must be observed. First, the CompactFlash card must be ordered separately and must be of high industrial quality; using standard consumer-grade cards can lead to data corruption or system failure due to vibration and temperature fluctuations.

Second, the Battery for the retentive memory and real-time clock has a finite lifespan; users should monitor the battery status through software diagnostics to avoid losing data during a power cycle. Third, ensure proper Electrostatic Discharge (ESD) Protection when handling the module, as the exposed backplane pins are sensitive to static. Finally, the Heat Dissipation must be considered; while fanless, the module requires specific mounting orientations and clearance distances within the control cabinet to allow for natural convection cooling.

Product Applications

The B&R X20CP1486 is widely deployed in industries that demand high precision and synchronization.

• Packaging Machinery: Coordinating high-speed motion for wrapping, labeling, and filling machines where timing is measured in microseconds.

• Plastic Processing: Controlling injection molding machines where complex temperature PID loops and pressure controls must run simultaneously.

• Renewable Energy: Managing wind turbine pitch and yaw control systems that require high reliability in harsh outdoor environments.

• Material Handling: Orchestrating complex sorting systems and automated guided vehicles (AGVs) that rely on real-time Ethernet communication for navigation.

• Automotive Production: Used in assembly cells and robotic interface units due to its ability to handle large volumes of I/O data across various bus systems.
