X-CB 005 04 HIMA Basis unit

Product  Description：

HIMA Base Units, primarily utilized within high-availability safety systems like the HIMax and HIMatrix series, serve as the foundational mechanical and electrical backplane chassis for safety-instrumented systems (SIS). These units provide the physical slot architecture and the redundant communication bus necessary to house and interconnect central processing units (CPUs), power supplies, and safety-related input/output (I/O) modules. Engineered specifically for emergency shutdown (ESD) and fire and gas (F&G) applications, they ensure uninterrupted operation and fail-safe performance.

Product Parameters

The technical baseline of a HIMA Base Unit emphasizes structural scalability, strict isolation, and high-bandwidth bus distribution:

• Slot Capacity: Offered in various compact and high-density sizes, typically featuring 4-slot, 8-slot, 15-slot, or 18-slot configurations to fit different cabinet dimensions.

• Backplane Bus Speed: Integrated with safe, high-speed Ethernet-based backplane communication protocols supporting microsecond-level synchronization between safety processors and I/O.

• Power Routing Redundancy: Dual-trace or triple-trace backplane power distribution lines designed to accommodate redundant 24V DC power supply modules without single points of failure.

• Dielectric Isolation: High electrical isolation between the backplane logic, power lines, and the frame ground, typically rated to withstand up to 500V AC or higher to prevent surge propagation.

• Mounting Flexibility: Designed for standard 19-inch rack installation or heavy-duty panel mounting within sealed industrial enclosures.

• Climate Resistance: Certified for extended temperature operations, typically from -20°C to 60°C, and up to 95 percent relative humidity under non-condensing conditions.

Product Advantages

HIMA Base Units are regarded as premium hardware solutions for critical safety applications due to their unique engineering traits:

• Uncompromised Safety Availability: Built to comply with SIL 3 (Safety Integrity Level 3) according to IEC 61508, ensuring that the physical backplane itself maintains the highest standards of hardware fault tolerance.

• Non-Stop Operation via Hot-Swapping: Supports full online replacement of any module, including the safety CPUs and power modules, without interrupting the active safety logic or causing false trips.

• Crosstalk and Noise Elimination: Advanced multi-layer PCB design within the backplane ensures maximum electromagnetic compatibility (EMC) and prevents signal crosstalk between high-speed communication lines and power rails.

• Physical Robustness: Constructed with vibration-resistant connection pins and ruggedized frame materials to withstand the harsh mechanical stresses found in heavy industrial plants.

• Scalable Architecture: Allows multiple base units to be linked together via certified safe ethernet networks, enabling seamless system expansion from small machine safety setups to plant-wide emergency networks.

Product Applications

These base units act as the core physical foundation for safety-critical control loops globally:

• Emergency Shutdown Systems (ESD): Hosting the core logic cards and input modules responsible for safely isolating plant sectors during a critical process upset.

• Fire and Gas Systems (F&G): Organizing the safety I/O necessary to monitor flame, smoke, and toxic gas detectors and activate deluge or suppression hardware.

• Burner Management Systems (BMS): Providing the stable hardware baseline for controlling start-up sequences, flame monitoring, and fuel safety shut-offs on large boilers and furnaces.

• Turbomachinery Control (TMC): Supporting high-speed overspeed protection systems for large steam turbines and compressors.

• Railway and Infrastructure Safety: Used in signaling control systems, tunnel ventilation safety networks, and automated train protection platforms.

Important Precautions

To preserve the safety integrity level and guarantee correct operation, the following guidelines must be strictly enforced:

• Frame Earthing Requirements: The base unit must be connected to a clean, low-impedance functional safety earth ground. Improper grounding can introduce noise that can lead to unexpected safety shutdowns or system faults.

• Slot Keying and Alignment: Ensure that module coding or keying mechanisms are properly configured before inserting hardware. Forcing a module into an incorrect or misaligned slot can bend the backplane pins and ruin the chassis connection.

• Slot Protective Covers: All empty slots on the base unit must be covered with official HIMA blank plates to maintain internal airflow patterns, ensure proper heat dissipation, and prevent ambient conductive dust from landing on exposed pins.

• Power Sequence Verification: Turn off all external field power lines before installing or removing field termination blocks attached to the base unit to prevent accidental short circuits that could trigger safety fuses.

• Mandatory Clearance Zones: Maintain the exact vertical and horizontal clearance gaps specified in the hardware manual around the base unit rack to allow for natural thermal convection, preventing heat buildup from stressing the internal components.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
