SGMDH-45A2B-YR13 YASKAWA

SGMDH-45A2B-YR13 YASKAWA Processor module

Product  Description：

Yaskawa Processor Modules serve as the primary computing engine for the MP (Machine Controller) series, such as the MP2000 and MP3000 lines. These modules are responsible for managing the high-speed coordination of motion commands, logic execution, and system-wide synchronization. Unlike a standard PLC processor, a Yaskawa Processor Module is optimized specifically for motion, featuring a high-speed bus architecture that ensures zero-lag communication between the CPU and servo drives.

Product Parameters

The technical performance of a Yaskawa Processor Module is defined by its ability to handle complex mathematical calculations in real-time:

• Scan Time Performance: Basic instruction execution speeds often reach as low as 1.25 nanoseconds, ensuring high-speed logic throughput.

• Motion Control Cycles: Supports ultra-fast synchronous cycles, typically selectable between 125 microseconds and 4 milliseconds depending on the number of axes.

• User Program Capacity: Large-scale memory options often reaching up to 32MB for complex structured text and ladder logic programs.

• Maximum Axis Support: Capable of controlling up to 32 physical axes per module, with the ability to expand via network modules to hundreds of axes.

• Data Storage: Integrated non-volatile memory (MRAM or Flash) to retain critical machine parameters and position data without the need for a battery in some models.

• Internal Communication: High-speed backplane interface that allows for high-bandwidth data exchange with I/O and communication modules.

Product Advantages

Yaskawa Processor Modules are recognized for their industry-leading motion performance and robust design:

• True Motion-Logic Integration: The processor manages both sequence control (PLC) and motion control (NC) within a single execution cycle, eliminating the communication delay found in dual-processor systems.

• Deterministic Performance: High-precision clock synchronization ensures that all axes receive motion commands simultaneously, which is critical for high-speed interpolation and multi-axis coordination.

• Advanced Math Capabilities: Specifically designed to handle floating-point calculations and trigonometric functions required for complex robot kinematics and winding applications.

• Reliability and Longevity: Built to withstand industrial electrical noise and vibration, Yaskawa processors are known for exceptionally long mean time between failures (MTBF).

• Comprehensive Development Environment: Fully supported by the MPE720 software, which provides sophisticated diagnostic tools, real-time tracing, and simulation capabilities.

Product Applications

The high processing power of these modules makes them suitable for the most demanding automation tasks:

• High-Speed Printing and Converting: Managing the precise synchronization of multiple rollers to maintain web tension and color registration.

• Electronic Assembly: Controlling high-speed surface mount technology (SMT) machines and precision pick-and-place robots.

• Robotics: Handling the inverse kinematics and path planning for 6-axis articulated robots or Delta-style parallel robots.

• Packaging Machinery: Coordinating complex movements for horizontal form-fill-seal machines and high-speed rotary cutters.

• Semiconductor Processing: Executing the nanometer-level positioning required for wafer handling and chemical mechanical polishing (CMP).

Important Precautions

To ensure the safety and operational integrity of the Yaskawa Processor Module, the following guidelines are required:

• Slot Positioning: Always install the processor module in the designated "CPU" slot of the base unit. Installing it in an I/O slot may cause electrical damage to the backplane.

• Module Replacement: Never remove or insert the processor module while the power is turned on. "Hot-swapping" the CPU can lead to data corruption or hardware failure.

• Memory Management: Before downloading a new program or performing a firmware update, always create a full backup of the existing project and machine parameters.

• Thermal Considerations: Ensure that the module is installed in a cabinet with adequate clearance for airflow. Do not exceed the maximum ambient temperature rating, as overheating can cause the CPU to throttle or trigger a watchdog error.

• Battery Maintenance: For modules that utilize a battery for memory retention, ensure the battery is replaced immediately when the "BAT" LED indicator flashes to prevent the loss of absolute encoder data and user programs.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
