SGD7S-2R8A00A002 YASKAWA

SGD7S-2R8A00A002 YASKAWA Central Control Unit

Product  Description：

Yaskawa Central Control Units, primarily represented by the MP3000 and MP2000 machine controller series, serve as the high-speed intelligence center for complex automated systems. These units are designed to unify motion control, logic sequences, and network communication into a single hardware platform. By utilizing a high-performance RISC processor and the proprietary MECHATROLINK industrial network, they achieve synchronous control over multiple axes with sub-millisecond precision, making them the standard for high-end motion applications.

Product Parameters

The technical foundation of Yaskawa Central Control Units focuses on processing speed and motion scalability:

• CPU Architecture: High-speed RISC (Reduced Instruction Set Computer) processor designed for simultaneous execution of logic and motion arithmetic.

• Motion Control Cycle: High-speed deterministic cycles, typically configurable at 125 microseconds, 250 microseconds, or 500 microseconds.

• Axis Synchronization: Supports up to 32 or 64 physical axes per unit, with the ability to manage hundreds of virtual axes for complex electronic camming.

• Communication Protocols: Integrated MECHATROLINK-III or MECHATROLINK-4 for motion, along with Ethernet (Modbus/TCP, EtherNet/IP) for enterprise-level data exchange.

• Programming Capacity: Large-scale memory support for complex ladder logic and high-level motion function blocks, often exceeding several megabytes.

• I/O Expansion: High-speed local bus for adding digital, analog, and specialized feedback modules without compromising cycle times.

Product Advantages

Yaskawa Central Control Units offer specific engineering benefits that distinguish them from standard PLCs:

• Motion-Logic Integration: Unlike standard controllers that treat motion as a peripheral task, Yaskawa units prioritize motion calculations, ensuring zero "jitter" in motor commands.

• Advanced Electronic Camming: Features sophisticated built-in camming and gearing functions that allow for mechanical-free synchronization of multiple motor movements.

• Global Reliability: Proven performance in high-vibration and high-temperature industrial environments, backed by Yaskawa’s strict quality control standards.

• Simplified Engineering: The MPE720 software environment allows users to program motion using graphical cam editors and standard PLC open function blocks, reducing development time.

• High-Speed Connectivity: The use of MECHATROLINK ensures that drive parameters, alarm data, and position feedback are all transmitted over a single digital cable at high speeds.

Product Applications

These control units are the core components in high-speed, high-accuracy machinery:

• Semiconductor Equipment: Managing the precise, rapid movements of wafer handling systems and precision lithography stages.

• Converting and Printing: Controlling electronic line shafts for printing presses and tension control for high-speed winding and slitting machines.

• Packaging Systems: Coordinating rotary cutters, flying shears, and high-speed delta robots for food and pharmaceutical packaging.

• Metal Working: Driving multi-axis CNC-style bending, spring forming, and wire-straightening machinery.

• Assembly Robotics: Acting as the master controller for multi-robot cells that require perfect synchronization with conveyor systems.

Important Precautions

To ensure long-term stability and prevent system errors, operators must observe the following:

• Electrical Noise Management: Use designated Yaskawa shielded cables for all MECHATROLINK connections and ensure the control unit is grounded to a common ground point to prevent electromagnetic interference (EMI).

• Proper Cooling: The high-speed processor generates heat; ensure the unit is mounted in the correct vertical orientation with at least 50mm of clearance above and below for airflow.

• Battery Maintenance: Many central units rely on a lithium battery to retain absolute encoder data and user programs during power-off states. Monitor battery alarms and replace them within the specified lifespan.

• Power Supply Integrity: Use a dedicated 24V DC power supply for the control unit that is separate from the power supply used for inductive loads like solenoids or relays to avoid voltage dips.

• Software Versioning: When replacing a central unit or adding expansion modules, ensure the firmware version of the CPU matches the version supported by your engineering software to avoid communication initialization failures.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
