SGD-01AP YASKAWA

SGD-01AP YASKAWA Interface Module

Product  Description：

Yaskawa Interface Modules are specialized communication and expansion components designed for the MP series machine controllers and Sigma series servo systems. These modules act as the vital link between the controller’s high-speed internal bus and various external networks, peripheral devices, or human-machine interfaces. By providing a standardized gateway for data exchange, these modules enable Yaskawa controllers to operate within complex, multi-vendor automation environments while maintaining the high-speed performance required for precision motion control.

Product Parameters

The technical specifications of Yaskawa Interface Modules focus on data throughput, protocol compatibility, and hardware connectivity:

• Supported Network Protocols: Broad range including MECHATROLINK (II, III, and 4), EtherCAT, Ethernet/IP, Modbus TCP/RTU, Profibus-DP, and DeviceNet.

• Communication Speed: High-speed digital interfaces like MECHATROLINK-III support up to 100 Mbps, while specialized serial interfaces operate at standard industrial baud rates.

• Transmission Cycle: Optimized for motion synchronization, with some interface modules supporting transmission cycles as fast as 125 microseconds.

• Maximum Node Capacity: Depending on the protocol, a single interface module can often manage up to 64 or 128 stations on a single network segment.

• Physical Connectors: Equipped with industrial-grade RJ45 ports for Ethernet-based protocols or D-sub connectors and terminal blocks for serial fieldbuses.

• Isolation Protection: Integrated galvanic isolation between the network signals and the internal controller circuitry to prevent damage from ground loops and electrical surges.

Product Advantages

Yaskawa Interface Modules provide several key benefits for high-end machine design:

• Seamless Motion Integration: Designed specifically to work with Yaskawa’s motion engine, these modules ensure that communication data is delivered with the strict determinism required for multi-axis synchronization.

• Plug-and-Play Expansion: The modular design allows for rapid system scaling. Adding a new communication standard to a machine is often as simple as inserting a new module into an open rack slot.

• Reduced Wiring Complexity: By using high-speed serial and Ethernet fieldbuses, these modules significantly reduce the amount of physical wiring required compared to traditional point-to-point analog or digital connections.

• Robust Diagnostics: Built-in status indicators and software registers provide real-time feedback on network health, link status, and data errors, which simplifies the commissioning and maintenance process.

• High EMI Resistance: Built to industrial standards, the modules feature superior shielding and noise filtration to ensure reliable data transfer even in environments with heavy electrical interference from high-power servo drives.

Product Applications

These modules are used in any scenario where the machine controller must interact with external hardware or higher-level systems:

• Distributed Motion Control: Connecting a central controller to remote servo drives and I/O stations located across a large production line via MECHATROLINK.

• Factory Information Systems: Bridging the gap between the machine level and the enterprise level by transmitting production data to SCADA or MES systems via Ethernet/IP or Modbus TCP.

• Third-Party Device Control: Interfacing Yaskawa controllers with third-party sensors, barcode readers, or specialized instruments that utilize Profibus or DeviceNet protocols.

• Human-Machine Interface (HMI): Providing the high-speed data link necessary for real-time visualization and operator control on touch panels and industrial PCs.

• Multi-Controller Synchronization: Enabling data sharing and coordination between multiple machine controllers to manage complex, integrated production cells.

Important Precautions

To ensure long-term reliability and accurate data transmission, the following precautions are required:

• Network Termination: For daisy-chained networks like RS-485 or Profibus, it is critical to install termination resistors at the first and last nodes to prevent signal reflection and data corruption.

• Cable Specifications: Use only Yaskawa-certified or high-quality industrial shielded cables. Low-grade cables can cause intermittent communication dropouts and timing jitter.

• Address Configuration: Ensure that every node on the network has a unique station address. Duplicate addresses will lead to network collisions and system-wide communication failure.

• Slot Limitations: Some interface modules have specific slot requirements on the controller base unit or limits on how many high-bandwidth modules can be used simultaneously. Always consult the hardware manual for the specific base unit.

• Grounding Continuity: Ensure that the shield of the communication cable is properly grounded through the connector housing or a dedicated grounding bar to maximize the module's noise immunity.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
