SA-4569-T Woodward

SA-4569-T Woodward Termination Unit

Product  Description：

A WOODWARD termination unit is a specialized electrical component designed to provide a secure and reliable connection point for various electrical signals and power within a control system. These units are typically used in industrial applications, especially in power generation, where robust and efficient connections are critical. Termination units can be customized to accommodate a wide range of connectors, terminals, and wiring configurations.

Key Functions

• Electrical Connection: Provides a secure and reliable connection point for electrical wires and cables.
• Signal Termination: Terminates electrical signals, ensuring proper impedance matching and signal integrity.
• Grounding: Provides a common ground reference for electrical components.
• Shielding: Protects against electromagnetic interference (EMI).
• Strain Relief: Reduces stress on wires and cables, preventing damage.

Product Parameters (Typical)

• Number of Terminals: The number of terminals available for connections.
• Wire Gauge: The range of wire gauges that can be accommodated.
• Connector Types: The types of connectors that can be used (e.g., screw terminals, crimp terminals, D-sub connectors).
• Mounting Type: The method of mounting the unit (e.g., panel mount, DIN rail mount).
• Material: The material used for the housing and terminals (e.g., metal, plastic).
• Ingress Protection: The level of protection against dust and water (IP rating).

Product Advantages

• Reliability: Designed for harsh industrial environments and long-term reliability.
• Flexibility: Can be customized to meet specific application requirements.
• Safety: Incorporates safety features to protect personnel and equipment.
• Compatibility: Compatible with a wide range of WOODWARD control systems.
• Modular Design: Allows for easy expansion and customization.

Precautions

• Compatibility: Ensure compatibility with other system components before installation.
• Torque: Tighten terminal screws to the specified torque to ensure a secure connection.
• Wire Stripping: Strip wires to the correct length to prevent damage to the insulation.
• Grounding: Ensure proper grounding to prevent electrical noise and shock hazards.
• Environmental Conditions: Operate within specified environmental limits.

Product Applications

WOODWARD termination units are used in a wide range of applications, including:

• Power Generation: Connecting sensors, actuators, and control devices in power plants.
• Industrial Automation: Providing connections for PLCs, HMIs, and field devices.
• Marine Propulsion: Terminating electrical connections in marine propulsion systems.
• Oil and Gas: Providing connections for equipment in refineries and pipelines.

Typical Applications

• Connecting sensors to a PLC.
• Terminating control signals for a motor drive.
• Providing power connections for a distributed control system (DCS).

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
