RJ61BT11 MITSUBISHI

RJ61BT11 MITSUBISHI Output Module

Product  Description：

Mitsubishi Electric Output Modules are essential components of the MELSEC PLC series, acting as the interface that translates digital commands from the CPU into physical actions. These modules control various output devices such as relays, solenoid valves, and motor starters. They are available in several types, including Relay, Triac (AC), and Transistor (DC) outputs, to meet diverse industrial requirements.

Product Parameters

Specific technical parameters vary depending on the output type, but general specifications include:

• Output Points: Available in configurations of 8, 16, 32, or 64 points per module.

• Rated Load Voltage: Supports 12V to 24V DC for transistor types and up to 240V AC for relay and triac types.

• Maximum Load Current: Typically ranges from 0.1A to 0.5A per point for transistor modules, and up to 2A per point for relay modules.

• Response Time: Fast switching speeds, with transistor modules responding in under 1ms, while relay modules typically require 10ms to 12ms.

• Surge Suppressor: Integrated varistors or diodes to protect the internal circuitry from inductive load kickback.

• Isolation Method: High-performance optocoupler or mechanical isolation (photocoupler or relay) between internal logic and output terminals.

Product Advantages

Mitsubishi Output Modules are engineered for precision and industrial resilience:

• High Switching Frequency: Transistor modules allow for rapid, repetitive switching without mechanical wear, making them ideal for high-speed pulse control.

• Robust Load Handling: Relay modules provide high current capacity and the flexibility to switch both AC and DC loads within a single module.

• Detailed Diagnostics: Many advanced modules feature LED indicators for each point and intelligent diagnostic functions to detect fuse blowouts or external power supply failures.

• Wiring Efficiency: Support for high-density connectors (such as 40-pin connectors) significantly reduces the space required in the control cabinet.

• Scalable Architecture: Easily integrated into local racks or remote I/O stations via high-speed networks like CC-Link IE Field.

Product Applications

These modules are widely deployed across various sectors to automate physical processes:

• Machine Tooling: Controlling the activation of spindles, coolant pumps, and hydraulic clamps in CNC machines.

• Material Handling: Managing conveyor belt motors, pneumatic pushers, and sorting gates in logistics centers.

• Process Control: Operating valves and heating elements in chemical processing or food and beverage production lines.

• Packaging Machinery: Synchronizing high-speed labeling, sealing, and wrapping operations.

• Building Automation: Controlling lighting systems and HVAC dampers in large-scale commercial facilities.

Important Precautions

To ensure stable operation and prevent hardware damage, the following precautions should be observed:

• Inductive Load Protection: When driving inductive loads (like solenoids), always use an external surge suppressor (diode for DC, surge killer for AC) to prevent voltage spikes from damaging the module.

• Common Terminal Current: Be mindful of the total current limit for the "Common" (COM) terminal. Exceeding this limit can cause overheating and permanent damage to the module's internal traces.

• Polarity Accuracy: For transistor output modules (Sink or Source types), ensure the polarity of the external power supply matches the module type to avoid short circuits.

• Fuse Replacement: If a fuse blows, investigate the root cause (such as an external short circuit) before replacing the fuse or the module.

• Hot Swapping Prohibited: Never install or remove the output module while the PLC power or external load power is turned on, as this can cause electrical arcing and data corruption.
