Product  Description：

The MX213 is a single-slot processor module based on an x86 architecture (specifically the AMD Geode LX industrial processor). It is optimized for small to medium-sized applications that require deterministic real-time behavior without the need for active cooling. The module integrates an internal power supply that provides energy for the attached I/O modules via the backplane, making it an efficient choice for decentralized or compact control cabinets. It supports various programming languages, including IEC 61131-3, C/C++, and MATLAB/Simulink, ensuring flexibility for diverse engineering requirements.

Product Parameters

• CPU Architecture: x86 / AMD LX Industrial Low-Voltage Processor

• Clock Frequency: $266 \text{ MHz}$ (Single Core)

• Main Memory: $256 \text{ MB}$ DRAM

• Retentive Memory: $512 \text{ kB}$ NVRAM (Retain) for data persistence during power loss

• Integrated Mass Storage: $64 \text{ MB}$ internal Flash (File-Flash)

• Removable Storage: Equipped with a CompactFlash (CF) card slot for expandable memory and a PC-Card slot

• Ethernet Interfaces: 2x 10/100 Base-TX (RJ45) ports supporting protocols like Modbus/TCP, EtherCAT, and PROFINET

• Serial Interfaces: 1x RS-232 and 1x RS-232/RS-422/RS-485 (configurable)

• Additional Ports: 1x CAN/CANopen interface and 1x USB 2.0 port

• Power Supply: $24 \text{ VDC}$ (nominal range $18$ to $34 \text{ VDC}$)

• I/O Power Output: Integrated supply providing up to $17 \text{ W}$ for connected modules

• Operating Temperature: $-30\text{°C}$ to $+60\text{°C}$ (Fanless operation)

• Dimensions: Approximately $110 \text{ x } 119 \text{ x } 61 \text{ mm}$ ($2$ module units wide)

Product Advantages

One of the most significant advantages of the MX213 is its Environmental Robustness, particularly the "ColdClimate" (CC) variant, which allows for reliable operation in extreme temperatures without moving parts like fans. The Real-Time Multitasking capability ensures that critical control loops and communication tasks run in parallel with absolute determinism. Its Compact Integration is another key benefit; by combining the CPU, power supply, and multiple communication interfaces (Ethernet, CAN, Serial) into a single module, it reduces the overall footprint and cabling of the automation system. Furthermore, the Seamless Scalability of the Bachmann platform allows users to migrate applications to more powerful CPUs in the future without rewriting the core application software.

Important Considerations and Precautions

When deploying the MX213, it is critical to observe Power Supply Stability; while the module has reverse polarity protection, a filtered $24 \text{ VDC}$ source is recommended to prevent noise interference. The I/O Power Limit must be strictly monitored; if the total power consumption of the connected I/O modules exceeds the $17 \text{ W}$ capacity of the integrated supply, an additional power module must be added to the rack. Users should also ensure that the CompactFlash Card used is of industrial grade to prevent data corruption during frequent write cycles. For maintenance, the Rechargeable Battery for the real-time clock should be checked if the system remains unpowered for extended periods, as it requires a powered backplane to maintain its charge.
