JANCD-MSV01B-2 YASKAWA

JANCD-MSV01B-2 YASKAWA Processor module

Product  Description：

Yaskawa Processor Modules serve as the primary control engine for the MP (Machine Controller) series, such as the MP2000 and MP3000 lines. These modules are the central processing units responsible for executing the system software, managing motion control synchronization, and coordinating communication across the backplane. Designed for high-speed industrial automation, they integrate logic and motion functions into a single hardware platform, providing deterministic performance for complex multi-axis machinery.

Product Parameters

The technical profile of a Yaskawa Processor Module is defined by its computational speed and high-density motion architecture:

• Control Cycle Time: Capable of high-speed motion loops ranging from 125 microseconds to 2 milliseconds, depending on the number of active axes and complexity of the logic.

• Programming Languages: Supports ladder logic, function blocks, and motion-specific instruction sets according to the MPE720 engineering environment.

• Axis Control Capacity: Manages varying axis counts, with entry-level modules handling up to 16 axes and high-end processors controlling 32 to 64 physical axes per module.

• Memory Capacity: Features non-volatile Flash ROM for user programs (ranging from 5MB to 20MB) and high-speed RAM for variable data and motion trajectory buffers.

• Communication Ports: Built-in high-speed interfaces typically include Ethernet (100Base-TX), MECHATROLINK-III for motion synchronization, and RS-485 for serial peripherals.

• Redundancy Support: Specialized versions support dual-processor configurations for mission-critical applications where system downtime is not permissible.

Product Advantages

Yaskawa Processor Modules are recognized for their motion-first architecture and long-term reliability:

• Unified Control Engine: By combining PLC logic and motion control into a single processor, the module eliminates the communication lag usually found between a standalone PLC and a separate motion controller.

• Superior Motion Precision: Delivers highly synchronized control of multiple axes, supporting electronic camming, gearing, and interpolation with minimal jitter.

• High Reliability: Designed without internal cooling fans (in many models) to reduce mechanical failure points, allowing the module to operate in dusty or vibration-prone industrial environments.

• Scalable Architecture: The modular design allows for the easy addition of communication or I/O modules, which the processor automatically recognizes and integrates into the scan cycle.

• Advanced Debugging Tools: Provides real-time trace functions that allow engineers to monitor motion profiles and logic execution at the microsecond level.

Product Applications

These processors are the core of high-performance machines across various industries:

• Robotics and Kinematics: Managing the complex mathematical calculations required for delta robots, SCARA robots, and custom multi-jointed arms.

• High-Speed Packaging: Controlling synchronized conveyor systems, rotary cutters, and "flying shear" applications where timing is measured in milliseconds.

• Semiconductor Processing: Driving ultra-precise wafer handling systems and polishing machines that require smooth, consistent motion.

• Textile and Paper Conversion: Managing high-speed winding, tension control, and material feeding systems with constant velocity requirements.

• Printing Machinery: Ensuring perfect color registration through electronic line shafting and high-speed synchronization across multiple printing stations.

Important Precautions

To ensure the safety and longevity of the Yaskawa Processor Module, the following guidelines must be followed:

• Battery Management: Many modules utilize a lithium battery to maintain data in the internal RAM. If the "Battery Low" indicator lights up, the battery must be replaced within the specified time to prevent the loss of parameters and programs.

• Backplane Installation: Never insert or remove the processor module while the power to the base unit is turned on. "Hot-swapping" can cause electrical surges that permanently damage the processor's internal circuitry.

• Firmware Compatibility: When upgrading the engineering software (MPE720), always verify that the processor's firmware version is compatible. Incompatible firmware can lead to system initialization errors or unstable motion control.

• Static Electricity Protection: The internal components are highly sensitive to electrostatic discharge. Always use an ESD wrist strap and handle the module by its edges or the plastic faceplate.

• Proper Grounding: Ensure that the Functional Ground (FG) terminal of the base unit is connected to a low-resistance earth ground. Poor grounding can lead to intermittent logic resets or communication errors in electrically noisy environments.
