JANCD-MIO02 YASKAWA

JANCD-MIO02 YASKAWA controller module

Product  Description：

Yaskawa controller modules are high-performance expansion units designed to work alongside the MP (Machine Controller) series and Sigma series central units. These modules allow for the customization of the control system by adding specific functionalities such as high-speed I/O, advanced analog processing, or specialized communication ports. By utilizing a modular backplane architecture, Yaskawa enables machine builders to tailor the controller’s hardware exactly to the requirements of the application, ensuring high-speed data throughput and deterministic control.

Product Parameters

The technical specifications of Yaskawa controller modules vary depending on the module type (I/O, Analog, or Communication), but generally include the following:

• Interface Type: Proprietary high-speed bus connection designed for seamless integration with the MP3000 or MP2000 series base units.

• Signal Density: Available in various densities, such as 16 or 32 points for digital modules, and 4 to 8 channels for high-resolution analog modules.

• Data Update Cycle: Synchronized with the main CPU control cycle, often achieving refresh rates as fast as 125 microseconds.

• Resolution: Analog modules typically offer 16-bit resolution to ensure precise feedback for motion-sensitive applications.

• Power Consumption: Optimized for low heat generation, typically drawing between 100mA and 500mA from the internal system power supply.

• Galvanic Isolation: Integrated optical or magnetic isolation (often rated at 1500V AC) to protect the central CPU from field-side electrical interference.

Product Advantages

Yaskawa controller modules are engineered to provide a balance of speed, precision, and industrial-grade durability:

• High-Speed Processing: These modules are designed to minimize the delay between signal acquisition and CPU processing, which is critical for maintaining high-speed motion synchronization.

• Scalable Architecture: Users can easily expand their system by adding modules to a rack, allowing for a cost-effective "pay-as-you-grow" approach to automation.

• Plug-and-Play Integration: Once inserted into the base unit, the modules are automatically recognized by the MPE720 engineering software, simplifying the configuration and mapping of addresses.

• Industrial Hardening: All modules are built to withstand high levels of vibration and shock, meeting stringent industrial standards for 24/7 operation in factory environments.

• Specialized Functionality: Beyond standard I/O, Yaskawa offers modules for specific tasks like high-speed counter inputs for encoders or pulse output modules for controlling stepper motors.

Product Applications

These modules are used to extend the capabilities of the machine controller across various industries:

• Assembly and Robotics: Using high-speed digital I/O modules to interface with pneumatic actuators and proximity sensors in robotic assembly cells.

• Precision Metalworking: Implementing analog input modules to monitor tool pressure and displacement in high-accuracy grinding or milling machines.

• Material Handling: Utilizing communication modules to link the machine controller with warehouse management systems or remote I/O stations over Mechatrolink or Ethernet.

• Converting and Printing: Applying specialized tension control modules to manage the high-speed winding and unwinding of paper, film, or foil.

• Packaging Systems: Coordinating sensors and actuators via high-density I/O modules for synchronized filling, sealing, and labeling operations.

Important Precautions

To ensure reliable operation and prevent hardware damage, the following precautions must be followed during installation and maintenance:

• Module Insertion: Always ensure the power to the base unit is completely turned off before inserting or removing any controller module. Failure to do so can cause an electrical surge that may damage the backplane or the module itself.

• Address Configuration: Verify the hardware dip switch settings (if applicable) and software address mapping to avoid conflicts with other modules in the same rack.

• Shielding and Grounding: When wiring analog or high-speed counter modules, use high-quality shielded cables. Ensure the shield is properly grounded to prevent electromagnetic interference from causing signal fluctuations.

• Ventilation Space: Maintain the recommended clearance around the controller rack as specified in the manual. Overheating can lead to intermittent logic errors or shortened component lifespan.

• Terminal Tightening: Regularly check the tightness of the wiring terminal screws, especially in environments with high vibration. A loose connection can cause false triggers or signal loss that is difficult to diagnose.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
