JACP-317215 YASKAWA

JACP-317215 YASKAWA I / O module

Product  Description：

Yaskawa I/O (Input/Output) modules are high-performance expansion units designed to work in conjunction with Yaskawa Machine Controllers, such as the MP series. These modules serve as the essential interface between the digital intelligence of the controller and the physical reality of the factory floor. They capture signals from field sensors and send commands to actuators, ensuring that the high-speed motion control for which Yaskawa is famous is perfectly synchronized with the rest of the machine's logic.

Product Parameters

The technical characteristics of Yaskawa I/O modules are optimized for high-speed industrial environments:

• Point Density: Available in various configurations including 8, 16, 32, or 64 points per module to accommodate different space and wiring requirements.

• Signal Types: Comprehensive range of modules supporting 24V DC (Sink/Source), 100V AC inputs, and Relay or Transistor (Sink/Source) outputs.

• Response Speed: Fast input response times typically adjustable between 0.1ms and 1ms, with transistor output switching speeds optimized for high-frequency operations.

• Isolation: High-voltage photocoupler isolation between the field side and the internal logic, often rated at 1500V AC or higher to prevent damage from electrical surges.

• Connection Interface: Offered with removable screw terminal blocks for easy maintenance or high-density D-sub and MIL connectors for compact wiring.

• Power Consumption: Low-draw architecture designed to operate efficiently from the controller's internal backplane power supply.

Product Advantages

Yaskawa I/O modules offer several distinct advantages for precision manufacturing:

• Tight Integration with Motion: Because these modules communicate directly over the high-speed backplane of the MP controller, there is minimal latency between an input signal (like a registration mark) and a motion command.

• High Reliability: Designed to withstand the rigorous vibrations and thermal stresses of machine-mounted applications, ensuring a long service life in 24/7 production environments.

• Ease of Troubleshooting: Most modules include clear LED status indicators for each I/O point, allowing maintenance personnel to diagnose sensor or actuator failures instantly.

• Compact Form Factor: The high-density 64-point modules allow for a significant reduction in control panel size, which is critical for modern, space-constrained machinery.

• Flexible Mapping: The I/O points are easily mapped and addressed within the MPE720 software environment, allowing for rapid configuration and logical grouping of signals.

Product Applications

These modules are found in a wide array of automated machinery:

• High-Speed Packaging: Detecting product presence and triggering pneumatic ejectors or labeling heads in millisecond timeframes.

• Robotics: Interfacing with end-of-arm tooling, safety interlocks, and palletizing sensors in robotic work cells.

• Material Handling: Managing the complex logic of high-speed sorting systems, conveyors, and automated guided vehicles (AGVs).

• Metal Working: Coordinating the status of safety guards, coolant pumps, and tool changers in CNC and milling centers.

• Semiconductor Processing: Managing the ultra-clean and highly precise environmental controls and vacuum valves required for wafer production.

Important Precautions

To ensure safe and stable operation, the following guidelines must be strictly followed:

• Voltage Compatibility: Never connect an AC signal to a DC input module or vice versa. Always verify the module’s voltage rating against the field power supply to avoid catastrophic hardware failure.

• Inductive Load Protection: When using transistor outputs to drive inductive loads like solenoids or relays, always use external surge suppressors (diodes for DC or varistors for AC) to prevent back-EMF damage.

• Wiring Segregation: Maintain physical separation between I/O signal wires and high-voltage motor power cables. Crossing these cables at 90 degrees or keeping them in separate ducts reduces the risk of noise interference.

• Terminal Tightening: Periodically check that terminal block screws are tightened. Loose connections due to machine vibration can cause intermittent signal failure or overheating at the connection point.

• Static Electricity: Always handle the modules by the edges or the front panel. Do not touch the backplane connectors or internal circuitry without proper ESD grounding to prevent invisible damage to sensitive components.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
