IS215VCMIH2C GE FANUK

GE Fanuc analog input modules are essential components within GE Fanuc PLC systems, designed to convert analog signals from field devices (e.g., sensors, transmitters) into digital values that can be processed by the PLC. These modules enable the PLC to monitor and control continuous processes in various industrial applications.

Key Functions

• Analog-to-Digital Conversion: Converts analog voltage or current signals into digital values.

• Signal Conditioning: May include filtering, scaling, and linearization of input signals.

• Data Acquisition: Acquires analog data from field devices.
• Communication: Transmits converted digital data to the PLC's CPU.

Product Parameters (Typical)

• Number of Channels: The number of analog input channels per module.
• Input Range: The range of analog voltage or current signals that can be accepted (e.g., 0-10V, 4-20mA).
• Resolution: The precision of the analog-to-digital conversion (e.g., 12-bit, 16-bit).
• Accuracy: The deviation of the converted digital value from the actual analog value.
• Conversion Time: The time taken to convert an analog signal into a digital value.
• Isolation: The degree of electrical isolation between input channels and the PLC system.
• Power Requirements: The voltage and current requirements of the module.
• Operating Temperature: The range of operating temperatures.

Product Advantages

• Versatility: Supports a wide range of analog input signals.
• Accuracy: Provides accurate and reliable analog-to-digital conversion.
• Flexibility: Configurable to meet specific application requirements.
• Compatibility: Compatible with various GE Fanuc PLC systems.

Precautions

• Wiring: Follow the manufacturer's wiring diagrams to ensure proper connections.
• Signal Levels: Ensure that the input signal levels are within the module's specified range.
• Isolation: Properly isolate input channels to prevent electrical interference.
• Environmental Conditions: Operate within specified environmental limits.

Product Applications

GE Fanuc analog input modules are used in various industrial automation applications, including:

• Process Control: Monitoring and controlling temperature, pressure, flow, and level in chemical, oil, and gas industries.
• Manufacturing: Monitoring and controlling machine parameters, such as speed, position, and force.
• Water and Wastewater: Monitoring and controlling water treatment and distribution processes.
• Power Generation: Monitoring and controlling power generation equipment.

Typical Applications

• Monitoring temperature in a chemical reactor.
• Measuring flow rate in a pipeline.
• Controlling the position of a valve.
• Monitoring the speed of a motor.
