IC755CSWO7CDACA-FY Emerson

IC755CSWO7CDACA-FY Emerson Input module

Product  Description：

The IC755CSW07CDACA-FY belongs to the QuickPanel+ family, which is engineered to bridge the gap between human-machine interaction and the Industrial Internet of Things (IIoT). It features a 7-inch widescreen TFT color display with an integrated multi-touch projected capacitive screen. Unlike traditional resistive touchscreens, this capacitive display is highly responsive—even when the user is wearing gloves—and provides a vivid user experience similar to a modern tablet but built for the rigors of an industrial floor. The unit runs on the Microsoft Windows Embedded Compact 7 operating system, providing a stable environment for demanding applications.

Product Parameters

• Display: 7.0 inch TFT LCD Widescreen (16:9 aspect ratio)

• Resolution: 800 x 480 pixels (WVGA)

• Touch Technology: Projected Capacitive (Multi-touch support)

• Processor: Freescale i.MX535 (1 GHz ARM Cortex A8)

• Memory: 512 MB DDR3 RAM and 512 MB NAND Flash

• Operating System: Windows Embedded Compact 7 (EC7)

• Power Supply: 24 VDC nominal (range typically $\pm 20\%$)

• Communication Ports: 1x 10/100 Ethernet port, 1x RS-232 serial port (5-pin), 1x RS-485 serial port, 2x USB 2.0 (Type A), and 1x Mini-USB (Type B)

• Storage Expansion: SD/SDHC card slot for additional data logging or application storage

• Enclosure Rating: IP65 / NEMA 4X (Front panel when mounted correctly)

• Bezel Type: GE Monogram / Emerson branded bezel

Product Advantages

The primary advantage of the QuickPanel+ is its 3-in-1 functionality. It serves as an Operator Interface (OI), a process controller, and a data historian simultaneously. This integration simplifies system architecture and reduces hardware costs. The high-performance 1 GHz processor ensures fast screen transitions and efficient handling of complex logic. Furthermore, it supports HTML5 web browsing and multimedia, allowing users to view training videos, technical manuals, or web-based reports directly on the factory floor. Its multi-touch interface allows for intuitive gestures like pinch-to-zoom, improving the speed of data analysis for operators.

Important Considerations

Users must ensure the power supply is a stable 24 VDC source, as fluctuations outside the $\pm 20\%$ range can lead to system instability or damage. When installing the unit, verify that the mounting gasket is correctly seated to maintain the IP65/NEMA 4X environmental rating against dust and moisture. Because this module contains a lithium battery for the real-time clock and memory backup, it should only be serviced by trained personnel, and the battery must be disposed of according to local environmental regulations. Additionally, for use in hazardous locations (Class I, Div 2), always ensure the power is disconnected before removing or installing the module to prevent sparks.

Product Applications

This HMI is widely used in sectors requiring high-resolution visualization and local control. In Oil and Gas, it is used for monitoring wellhead data and controlling separators. In Water and Wastewater, it manages pump station diagnostics and flow reporting. It is also common in Food and Beverage packaging lines where high-speed synchronization between the HMI and the controller is necessary. Because it supports various IEC programming languages (such as Ladder Diagram and Structured Text), it can function as a stand-alone controller for smaller machines or as a sophisticated interface for larger PACSystems RX3i architectures.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year
