IC693PWR330H GE FANUK

GE Fanuc, now part of Emerson Automation Solutions, offered a variety of output modules for their programmable logic controllers (PLCs). These modules are essential components in industrial automation systems, enabling the PLC to control external devices and actuators. Output modules act as the interface between the PLC's control logic and the real-world equipment they manage.

Key Functions:

• Signal Conversion: Receive digital signals from the PLC and convert them into the appropriate electrical signals to drive output devices.
• Actuation: Control various output devices such as valves, relays, motors, lights, and solenoids.

• Isolation: Provide electrical isolation between the PLC and the field devices, protecting the PLC from voltage spikes and noise.
• Status Indication: Often include LEDs to indicate the status of each output point, aiding in troubleshooting.

Product Parameters (Typical)

• Output Type:
  • Digital (Discrete): On/off control of devices.
    • Relay Outputs: Use electromechanical relays to switch higher voltage and current loads.
    • Transistor Outputs: Solid-state switching for faster response times and higher switching frequencies.


  • Analog: Provide a variable voltage or current output to control devices like valves or actuators that require proportional control.

• Voltage and Current Ratings: Specify the voltage and current levels that the module can handle for both input and output.
• Number of Output Points: The number of individual outputs the module can control.
• Isolation Voltage: The maximum voltage the module can withstand between the PLC and field devices.
• Response Time: The time it takes for the output to change state after receiving a signal from the PLC.
• Communication Protocols: Some modules may support communication protocols for diagnostics and data exchange.

Product Advantages

• Reliability: Designed for harsh industrial environments with robust construction and components.
• Versatility: Wide range of modules available to suit various applications and output device requirements.

• Compatibility: Seamless integration with GE Fanuc PLCs and other automation equipment.
• Ease of Use: Simple installation and configuration with clear documentation and user-friendly interfaces.
• Diagnostics: Built-in diagnostics and status indicators for easy troubleshooting.

Precautions

• Proper Selection: Choose the correct output module based on the type and specifications of the output devices being controlled.
• Wiring: Follow wiring diagrams carefully to ensure correct connections and avoid damage to the module or other equipment.
• Overload Protection: Do not exceed the voltage and current ratings of the module to prevent damage.
• Environmental Conditions: Ensure the module is installed in an environment that meets the specified temperature, humidity, and vibration requirements.
• Safety: Always follow proper safety procedures when working with electrical equipment.

Product Applications

GE Fanuc output modules are used in a wide range of industrial automation applications, including:

• Manufacturing: Controlling machines, robots, and other automation equipment.
• Material Handling: Controlling conveyors, sorting systems, and other material handling equipment.
• Packaging: Controlling packaging machines and related equipment.
• Process Control: Controlling valves, pumps, and other process equipment.
• Building Automation: Controlling lighting, HVAC, and other building systems.

Typical Applications

• Controlling solenoid valves in a pneumatic system.
• Switching motors on and off for material handling.
• Dimming lights in a building automation system.
• Positioning an actuator in a process control application.
