HC-SFS52B MITSUBISHI

HC-SFS52B MITSUBISHI programmable controller module

Product  Description：

Mitsubishi Electric’s programmable controller modules, primarily under the MELSEC brand, serve as the industrial "brain" for automation systems worldwide. These modules are designed to manage complex logic, motion control, and data processing in a modular format. The lineup includes the high-performance MELSEC iQ-R Series for advanced applications, the versatile MELSEC-Q Series, and the compact MELSEC iQ-F Series. Each system consists of a base unit or rack where various modules—such as CPUs, Power Supplies, I/O units, and specialized Communication modules—are inserted to create a customized automation solution.

Product Parameters

While specific parameters vary significantly across different series, the following core specifications define the performance of Mitsubishi modules:

• Program Capacity: Ranges from 10k steps in compact models to over 1200k steps in high-end iQ-R CPUs.

• Scan Time/Processing Speed: Basic instruction speeds can be as fast as 0.14 nanoseconds, ensuring real-time responsiveness for high-speed machinery.

• I/O Points: Systems can scale from small configurations with 30 points to massive networks supporting up to 4096 local I/O points and tens of thousands of remote points.

• Operating Voltage: Standard modules typically operate on 24V DC for I/O, while power supply modules handle 100-240V AC or 24V DC.

• Communication Protocols: Built-in support for CC-Link IE, Ethernet/IP, SLMP, and Modbus/TCP.

Product Advantages

The primary reason for the widespread adoption of Mitsubishi modules is their reputation for "rock-solid" reliability and engineering flexibility.

• High-Speed Processing: The dedicated "multi-CPU" architecture allows for high-speed data transfer between the PLC, Motion, and Robot controllers on a single backplane.

• Backward Compatibility: Mitsubishi has a strong history of ensuring that newer systems can integrate with older hardware or software, protecting the user's long-term investment.

• Global Standardization: These modules comply with international standards such as CE, UL, and cUL, making them suitable for export-ready machinery.

• Scalability: The modular design allows users to start with a basic setup and add specialized modules for positioning, temperature control, or networking as the project grows.

Important Considerations and Precautions

To ensure the longevity and safety of the controller system, users should adhere to the following guidelines:

• Environmental Conditions: Modules should be installed in a clean, dry environment. Avoid areas with high concentrations of conductive dust, corrosive gases, or extreme vibrations.

• Wiring Safety: Always power down the entire system before installing or removing a module to prevent electrical surges or damage to the backplane connectors.

• Battery Maintenance: For modules that use memory backup batteries, ensure they are replaced according to the maintenance schedule to prevent the loss of critical program data.

• Heat Dissipation: Maintain proper spacing within the control cabinet as specified in the manual to allow for natural convection or forced-air cooling.

Product Applications

Mitsubishi programmable controller modules are utilized across nearly every sector of modern manufacturing:

• Automotive Industry: Controlling complex assembly lines, robotic welding stations, and paint shop conveyors.

• Semiconductor Manufacturing: Managing ultra-precise motion control and cleanroom environmental systems.

• Food and Beverage: Automating high-speed packaging, bottling lines, and temperature-controlled processing.

• Water Treatment: Supervising remote pumping stations and chemical dosing systems via wide-area networking modules.

• Material Handling: Driving automated storage and retrieval systems (AS/RS) and sophisticated sorting machines.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year
