GT15-AC50B MITSUBISHI

GT15-AC50B MITSUBISHI communication module

Product  Description：

Mitsubishi Electric Communication Modules are high-performance networking components designed for the MELSEC PLC series. These modules facilitate the integration of industrial automation systems into larger network architectures, enabling the exchange of control data, production statistics, and diagnostic information. They support various industrial Ethernet and fieldbus standards, allowing the PLC to serve as a central hub in a connected factory environment.

Product Parameters

The technical profile of a Mitsubishi Communication Module is defined by its throughput and networking flexibility:

• Protocol Support: Fully compatible with CC-Link IE TSN, CC-Link IE Field, CC-Link, Ethernet/IP, Profibus DP, and Modbus TCP/RTU.

• Data Transmission Speed: Supports high-speed fiber or copper Ethernet at 1 Gbps for TSN modules, and standard 100 Mbps for older iQ-F or Q-Series Ethernet modules.

• Connection Capacity: Capable of handling up to 128 simultaneous socket connections for Ethernet communications, allowing multiple devices to access the PLC concurrently.

• Maximum Station Count: Depending on the network type, a single module can manage up to 120 slave stations or remote I/O blocks.

• Buffer Memory Size: Equipped with internal user-accessible buffer memory (typically 512 KB to 2 MB) for efficient data queuing and asynchronous communication.

• Power Consumption: Optimized for efficiency, generally drawing 0.4A to 0.8A from the internal backplane power supply.

Product Advantages

Mitsubishi Communication Modules provide the backbone for modern digital manufacturing through several key strengths:

• Synchronized Control: Modules utilizing CC-Link IE TSN allow for the synchronization of motion control and general I/O data on a single network cable, reducing wiring complexity and improving precision.

• High Noise Immunity: Built with advanced shielding and industrial-grade isolation, these modules maintain data integrity even in environments with heavy electromagnetic interference from large motors or high-voltage lines.

• Simplified Configuration: Integrated within the GX Works3 software environment, these modules offer "Label-based" programming and intuitive network configuration tools that eliminate the need for complex manual register mapping.

• Real-time Diagnostics: Advanced built-in monitoring tools allow users to view network status, packet error rates, and station connectivity directly from the PLC software or a web-based interface.

• Scalability: The modular nature allows for the easy addition of different network types to a single PLC rack, enabling a machine to communicate with a European Profibus-based sensor and a Japanese CC-Link-based actuator simultaneously.

Product Applications

These modules are deployed in scenarios requiring high-speed data movement and cross-platform connectivity:

• Smart Factory Integration: Connecting individual machine controllers to a centralized SCADA or MES (Manufacturing Execution System) for real-time production tracking.

• Multi-Axis Motion Control: Linking the main PLC to servo drives and frequency inverters over a high-speed motion network for perfectly synchronized movement.

• Remote I/O Expansion: Managing distributed input and output points across a large facility without the need for extensive long-distance hardwiring.

• Third-Party Hardware Interfacing: Enabling the PLC to communicate with vision systems, barcode readers, and smart instruments from different manufacturers.

• Global Infrastructure Monitoring: Facilitating communication between distributed controllers in water treatment plants, power grids, or building management systems.

Important Precautions

To ensure a stable and secure network, the following precautions should be strictly followed:

• Network Topology Rules: Adhere strictly to the maximum cable lengths and the number of allowed switches for the specific protocol being used (e.g., star vs. line topology).

• Dedicated Network Hardware: For high-performance networks like CC-Link IE, always use industrial-grade managed switches that support the specific protocol requirements to prevent data collisions.

• IP Address Management: Maintain a rigorous log of IP addresses to avoid conflicts. In industrial networks, a single duplicate IP can cause an entire production line to stop.

• Shielding and Grounding: Ensure that the shield of the communication cable is properly grounded at the designated points to prevent noise from corrupting data frames.

• Security Configuration: Always change default passwords and disable unused services (like FTP or HTTP) within the module settings to protect the control system from unauthorized network access.
