FX3G-14MT/ES-A MITSUBISHI Multi-Function Processor Module

Product  Description：

The Multi-Function Processor system integrates advanced PID control, redundant capabilities, and high-speed data processing into a single modular architecture. Unlike standard PLCs that focus primarily on discrete manufacturing, this module is engineered for "Hybrid" control—handling both sequence control and continuous process control.

When configured in a redundant system, the module uses a dedicated optical fiber tracking cable to synchronize data between a "Control" CPU and a "Standby" CPU. This ensures that in the event of a hardware failure, the system can switch over in milliseconds without interrupting the controlled process or losing critical data.

Product Parameters

The following specifications represent the standard performance metrics for the iQ-R series Multi-Function and Redundant modules:

• Programming Capacity: Supports from 80K steps up to 1200K steps depending on the specific CPU model paired with the module.

• Instruction Processing Speed: LD instruction execution at approximately 0.98 nanoseconds.

• PID Loop Capacity: Capable of executing up to 300 loops with high-speed 50ms scan cycles.

• Tracking Data Capacity: Up to 1 million words can be synchronized between redundant units.

• Tracking Cable Type: Multi-mode optical fiber cable with a maximum distance of up to 550 meters.

• Interface: Built-in USB 2.0 and Ethernet (100BASE-TX) for seamless integration with SCADA and IT systems.

• Operating Temperature: 0 to 55 degrees Celsius for standard models, with extended ranges available for specialized modules.

Product Advantages

One of the primary advantages of this module is its scalability. Users can start with a small-scale standalone process and expand to a large-scale redundant system without changing the programming environment.

It also offers high availability. By minimizing single points of failure through multi-level redundancy—at the CPU, power supply, and network levels—the module ensures that critical systems like water treatment or chemical processing stay online.

Furthermore, the integration with GX Works3 software simplifies the development of complex PID loops using dedicated Function Block Diagram (FBD) languages, which reduces engineering time and human error.

Precautions

When installing and operating the Multi-Function Processor Module, certain safety and technical precautions must be observed:

• Power Management: Always turn off the external power supply before mounting or removing the module to prevent electric shock or internal circuit damage.

• Wiring Separation: Control lines and communication cables must be kept at least 100mm away from main circuit lines or power cables to prevent malfunction due to electromagnetic interference.

• Memory Protection: Do not write data to the "System Area" or "Write-Protect Area" of the buffer memory, as this can cause the programmable controller system to crash.

• Environmental Protection: Ensure that the module is installed in a clean environment. Dust, wire chips, or conductive foreign matter entering the module can cause fire or equipment failure.

• Redundancy Matching: When using a redundant configuration, ensure that both CPU modules are of the same model and version to maintain synchronization.

Product Applications

The Multi-Function Processor Module is widely used in industries where downtime is costly or hazardous:

• Water and Wastewater Treatment: Managing complex flow rates, chemical dosing, and filtration cycles that require constant monitoring and PID regulation.

• Chemical and Petrochemical: Controlling temperature, pressure, and reaction timing in environments where process stability is critical for safety.

• Food and Beverage: Automating pasteurization, mixing, and batching processes that require precise ingredient control and high hygienic standards.

• Power Generation: Managing auxiliary systems and fuel control where high reliability and fast response times are essential for grid stability.
