FX2N-48MR-001 Mitsubishi Analog Output Modules

Product  Description：

Mitsubishi Electric offers a comprehensive range of Analog Output Modules, primarily designed for their MELSEC series PLCs (Programmable Logic Controllers), such as the iQ-R, iQ-F, Q, and L series. These modules are responsible for converting digital signals from the PLC CPU into precise analog voltage or current signals to control external industrial devices.

Technical Specifications

The specifications of these modules vary depending on the specific series, but they generally adhere to the following technical standards:

• Output Channels: Usually available in 2, 4, or 8 channels per module.

• Output Ranges: Supports standard industrial signals including 0 to 5V DC, 1 to 5V DC, -10 to +10V DC, and 0 to 20mA or 4 to 20mA DC current loops.

• Resolution: High-precision conversion typically ranging from 12-bit to 16-bit binary. High-end modules can reach a resolution of 1/32000.

• Conversion Speed: Rapid response times, often as low as 80 microseconds per channel in high-speed models like the iQ-R series.

• Isolation Method: Most modules feature photocoupler isolation between the output terminals and the internal PLC power to prevent electrical noise interference.

Key Product Advantages

Mitsubishi analog modules are recognized in the industry for their reliability and ease of integration.

• High Precision and Stability: They provide extremely accurate signal reproduction, which is critical for fine-tuning processes where small fluctuations can affect quality.

• Scaling Functionality: Many modules allow for "Digital Values" to be automatically scaled to "Engineering Units" (like Celsius or Liters/min) directly within the module settings, reducing the need for complex PLC programming.

• Galvanic Isolation: The robust isolation protects the PLC system from external surges and ground loops, ensuring long-term hardware durability.

• Seamless Integration: Designed to work natively with GX Works2 or GX Works3 software, making configuration via "Parameter Settings" straightforward without requiring extensive manual coding.

Important Considerations and Precautions

To ensure optimal performance and prevent hardware damage, users should observe the following:

• Wiring Separation: Always separate analog output signal lines from high-voltage AC power lines or motor cables to avoid electromagnetic interference (EMI).

• Shielding: Use shielded twisted-pair cables for all analog signals and ensure the shield is properly grounded at a single point.

• External Power Supply: Many modules require an external 24V DC power supply to drive the output current loops; verify the power requirements in the specific manual before installation.

• Load Resistance: Ensure the connected device's impedance stays within the module's allowable load resistance range (e.g., typically 0 to 600 ohms for current outputs).

Typical Industrial Applications

These modules act as the "hands" of the PLC, allowing it to manipulate the physical environment.

• Inverter Control: Providing a 0-10V signal to a Variable Frequency Drive (VFD) to control the speed of a motor.

• Valve Positioning: Modulating the opening percentage of proportional valves in fluid control systems.

• Temperature Regulation: Sending signals to power controllers or heaters to maintain specific thermal profiles.

• Actuator Command: Controlling linear actuators or hydraulic systems in precision manufacturing and assembly lines.
