FX2N-16CCL-M MITSUBISHI

FX2N-16CCL-M MITSUBISHI Digital Input Module

Product  Description：

Mitsubishi Electric Digital Input Modules are core components of the MELSEC PLC series, acting as the sensory interface for industrial automation systems. These modules convert incoming electrical signals from field devices, such as switches, sensors, and encoders, into digital logic that the PLC CPU can process to execute control sequences.

Product Parameters

The technical profile of these modules varies depending on whether they belong to the iQ-R, iQ-F, or Q series, but generally include the following specifications:

• Input Type: Available in DC input (usually 24V), AC input (100-120V or 200-240V), and contact input types.

• Point Density: Standard configurations offer 8, 16, 32, or 64 points per module to accommodate different scale requirements.

• Input Current: Typically 4mA to 7mA per point for 24V DC inputs, ensuring low power consumption.

• Response Time: Features adjustable filter times, with high-speed modules capable of response times as fast as 0.1 milliseconds.

• Isolation Method: Utilizes photocoupler isolation between the input terminals and the internal PLC circuitry to prevent electrical damage.

• Connection Method: Options include removable terminal blocks, 40-pin connectors, or MIL connectors for high-density wiring.

Product Advantages

Mitsubishi Digital Input Modules are engineered for precision and longevity in industrial environments:

• High-Speed Processing: Compatible with the backplane speeds of the iQ-R series, allowing for near-instantaneous data acquisition for high-precision applications.

• Exceptional Reliability: Designed with high-quality internal components that resist electrical aging, ensuring the module remains accurate over millions of switching cycles.

• Flexible Filtering: Users can configure digital filters to eliminate "chatter" or mechanical noise from physical switches, preventing false triggers.

• Diagnostic Capabilities: Advanced modules feature LED status indicators for every point and software-based diagnostics to detect wire breakage or power loss.

• Scalability: The modular design allows for easy expansion, enabling users to add input capacity without replacing the existing control architecture.

Product Applications

These modules are used wherever physical states need to be monitored by a control system:

• Production Line Monitoring: Tracking the position of parts using limit switches or photoelectric sensors on a conveyor belt.

• Safety Interlocks: Monitoring the status of emergency stop buttons and safety door sensors to ensure operator protection.

• Machine Tooling: Detecting the "Home" and "End" positions of axes in CNC machines and robotic work cells.

• Packaging Machinery: Counting products as they pass through sensors to manage batching and labeling processes.

• Building Automation: Receiving signals from smoke detectors, motion sensors, and light switches for centralized facility management.

Important Precautions

To ensure stable operation and prevent hardware failure, observe the following guidelines:

• Polarity Awareness: For DC input modules, ensure the common (COM) terminal is wired correctly (sink vs. source) according to the module's specification.

• Inductive Load Protection: When inputs are connected to devices with inductive properties, use external surge suppressors to prevent back-EMF from damaging the photocoupler.

• Wiring Separation: Keep input signal wires separate from high-voltage power lines and motor drive cables to avoid electromagnetic interference and accidental triggering.

• Tightening Torque: Ensure terminal block screws are tightened to the specified torque; loose connections can cause intermittent signals or overheating.

• Environmental Sealing: While the module is robust, the overall PLC cabinet must be rated for the environment to protect the module from conductive dust and corrosive gases.
