FX1N-14MR-001 MITSUBISHI

FX1N-14MR-001 MITSUBISHI Operator unit

Product  Description：

The Mitsubishi Operator Unit, commonly referred to as the GOT (Graphic Operation Terminal), is a high-performance Human-Machine Interface (HMI). It acts as the primary communication bridge between operators and industrial automation equipment, such as PLCs, inverters, and servo drives. These units are designed to visualize data, control processes, and monitor system health in real-time.

Technical Specifications

While specific parameters vary across different series such as the GT27, GT25, or GT21, the general technical framework includes the following:

• Display Technology: High-resolution TFT LCD screens ranging from 3.8 inches to 15 inches, supporting up to 65,536 colors.

• Processing Power: Equipped with high-speed processors to ensure smooth screen switching and rapid data logging.

• Memory Capacity: Built-in user memory (ROM) for storing screen designs and internal RAM for temporary data processing.

• Communication Interfaces: Integrated ports for Ethernet, RS-232, RS-422/485, and USB. High-end models often include wireless LAN options.

• Storage Expansion: Support for SD memory cards for backup, data logging, and program updates.

• Environmental Protection: Front panel ratings often reach IP67F or IP65, providing resistance against water and oil splashes.

Core Product Advantages

• Seamless Integration: These units offer native compatibility with Mitsubishi Electric’s automation suite, allowing for easy "plug-and-play" setup with MELSEC controllers.

• Intuitive Operation: Multi-touch and gesture control (on high-end models) allow users to zoom, scroll, and operate the interface as easily as a smartphone.

• Advanced Troubleshooting: Integrated diagnostic functions allow operators to monitor PLC ladder programs directly from the HMI, reducing the need for a separate laptop on the factory floor.

• Robust Durability: Designed for harsh industrial environments, featuring high vibration resistance and wide operating temperature ranges.

• Enhanced Connectivity: The ability to act as a gateway, allowing remote access via PCs or tablets for off-site monitoring and maintenance.

Critical Considerations and Precautions

• Power Supply: Ensure the input voltage matches the specific model requirements (typically 24V DC or 100-240V AC) to prevent internal circuit damage.

• Installation Environment: Avoid installing the unit in areas with direct sunlight, high corrosive gas concentrations, or excessive conductive dust.

• Screen Maintenance: Clean the display with a soft, dry cloth. Using harsh chemicals or sharp objects can damage the touch-sensitive overlay.

• Data Backup: Regularly back up project files and logging data to an SD card or external server to prevent data loss during hardware failure.

• Battery Replacement: Monitor the internal battery life; this battery maintains the clock data and certain system memories when the power is off.

Common Industry Applications

• Automotive Manufacturing: Used in assembly lines for monitoring robot status, torque data, and production cycle times.

• Food and Beverage: Controlling packaging machines and monitoring temperature/pressure levels in processing tanks.

• Water Treatment: Visualizing pump station operations, flow rates, and chemical dosage levels.

• Semiconductor Production: Precise monitoring of cleanroom environments and high-speed wafer handling systems.

• Textile Industry: Managing complex weaving patterns and motor speeds across large-scale machinery.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year
