FR-A720-75K MITSUBISHI

FR-A720-75K MITSUBISHI Circuit Board

Product  Description：

Mitsubishi Electric is a global leader in the manufacturing of high-performance circuit boards, primarily focusing on Power Modules (like IGBTs), Industrial Control Boards, and Specialized PCBs for automation. These components are designed to manage power conversion and signal processing with extreme reliability in harsh industrial environments.

Product Parameters

The technical specifications of a Mitsubishi circuit board vary depending on the specific series (such as the MELSEC series for PLCs or the M80/M800 series for CNC), but they generally adhere to these standards:

• Voltage Ratings: Capable of handling low-voltage logic signals up to high-voltage power applications reaching 600V, 1200V, or 1700V in power modules.

• Current Capacity: Ranges from milliampere levels for control circuits to several hundred amperes for power drive boards.

• Operating Temperature: Standard industrial grade typically ranges from -20°C to +60°C, while specialized modules can withstand junction temperatures up to 150°C.

• Material Composition: High-grade FR-4 or Ceramic substrates for enhanced thermal dissipation and structural integrity.

• Communication Protocols: Integration of CC-Link, Ethernet/IP, and RS-422/485 interfaces for seamless industrial networking.

Product Advantages

Mitsubishi circuit boards are favored in the industry for several key reasons:

• High Durability: Built to withstand electrical noise, vibration, and thermal cycling, ensuring a long service life in factory settings.

• Energy Efficiency: Advanced semiconductor technology reduces power loss during switching, which is critical for sustainable industrial operations.

• Compact Design: High integration of components allows for smaller footprints, helping manufacturers save space within control cabinets.

• Precision Control: These boards offer high-speed processing capabilities, ensuring real-time response for complex motion control and automation tasks.

Precautions for Use

To maintain the integrity of the board and ensure safety, the following guidelines should be followed:

• Static Protection: Always use ESD (Electrostatic Discharge) wrist straps and mats when handling the boards to prevent invisible damage to sensitive microchips.

• Thermal Management: Ensure adequate airflow or heat sinking. Overheating is the primary cause of premature circuit failure.

• Correct Wiring: Strictly follow the terminal pinout diagrams. Incorrect polarity or voltage input can lead to immediate board burnout or fire hazards.

• Environment Control: Avoid installation in areas with high humidity, conductive dust (like metal shavings), or corrosive gases unless the board is housed in an appropriately rated (IP65+) enclosure.

Product Applications

Mitsubishi circuit boards are the "brains" and "muscles" behind various modern technologies:

• Industrial Automation: Found in Programmable Logic Controllers (PLCs) and Human Machine Interfaces (HMIs) used to manage assembly lines.

• CNC Machinery: Driving the precision motors and logic systems in lathes, milling machines, and grinders.

• Renewable Energy: Used in wind turbine pitch control and solar power inverters to manage energy conversion.

• Elevator Systems: Controlling the lift logic, safety protocols, and motor drives in commercial and residential elevators.

• Automotive: Power modules are often utilized in the drive trains of electric and hybrid vehicles for efficient battery management.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
