EVF8217-E LENZE

EVF8217-E LENZE Central Control Unit

Product  Description：

Lenze Central Control Units, primarily represented by the Controller c300, c500, and c700 series, serve as the high-performance computational core for modern, motion-centric machine automation. These controllers combine standard Programmable Logic Controller (PLC) functionalities with advanced motion control capabilities into a single, compact device. Running on real-time operating systems and optimized for EtherCAT communication, Lenze Central Control Units provide the deterministic execution required for complex multi-axis synchronized movements.

Product Parameters

The technical baseline of a Lenze Central Control Unit emphasizes processing speed, axis capacity, and synchronized cycle times:

• Processor Architecture: Equipped with high-efficiency Intel Atom or ARM processors depending on the specific model tier to handle demanding motion calculations.

• Motion Cycle Time: Supports ultra-fast processing cycles, down to 1 millisecond or less for real-time synchronization of field devices.

• Axis Control Capacity: Capable of controlling from 4 up to more than 64 synchronized axes using electronic camming, robotics profiles, and coordinated motion.

• Operating System: Utilizes a robust real-time operating system (RTOS) paired with a CODESYS-based runtime environment for deterministic program execution.

• Integrated Interfaces: Features standard onboard connections including EtherCAT (Master), Ethernet (TCP/IP, OPC UA), USB, and CANopen ports.

• Memory Capacity: Large non-volatile flash memory for application programs and high-speed RAM for retaining active system variables and motion parameters during a power cycle.

Product Advantages

Lenze Central Control Units stand out due to their motion-centric design philosophy and ease of engineering integration:

• Seamless Motion Integration: Built from the ground up for motion applications, these units easily manage complex electronic gearing, cam profiles, and interpolation without requiring auxiliary motion cards.

• Open Standards Architecture: Based on the global CODESYS standard (IEC 61131-3), allowing engineers to program in their preferred language while leveraging Lenze's extensive library of pre-tested motion function blocks.

• Future-Proof Connectivity: Built-in OPC UA compliance simplifies the bridge between factory floor hardware and upper-level cloud infrastructure or ERP systems for Industry 4.0 implementations.

• High Reliability and Diagnostics: Fanless design with no moving parts ensures long-term maintenance-free operation in industrial environments, supported by extensive online web-diagnostics.

• Space-Saving Modular Concept: Compact housing design saves valuable control cabinet space, while allowing direct expansion via local or remote I/O systems.

Product Applications

These control units are widely utilized in machinery where high-speed precision and motion coordination are paramount:

• Packaging Machinery: Governing synchronized motion for top-loading robots, flow-wrappers, filling systems, and high-speed labeling machinery.

• Material Handling and Logistics: Coordinating automated storage and retrieval systems (ASRS), high-speed sorters, palletizers, and continuous conveyor lines.

• Textile Production Equipment: Managing precise electronic line shafts and tension control loops across multi-station spinning and weaving machines.

• Printing and Converting Systems: Controlling winding and unwinding processes, tension regulation, and registration marks on high-speed continuous webs.

• Assembly and Robotics Systems: Driving delta robots, gantry systems, and pick-and-place mechanisms in automated assembly cells.

Important Precautions

To maintain control system stability and protect internal electronics, the following instructions must be strictly observed:

• Power Conditioning: Always use a stabilized, industrially rated 24V DC power supply. Voltage dips below the minimum specified tolerance can cause processor resets or safe-state shutdowns during active motion loops.

• Bus Termination and Topology: When setting up the EtherCAT network, ensure the correct topology is adhered to and that any auxiliary fieldbus lines (like CANopen) are properly terminated to prevent data packet corruption.

• Heat Dissipation Clearances: Ensure the unit is mounted in the correct vertical orientation with specified clearance spacing above and below the housing to allow for adequate natural convection cooling.

• Program and Parameter Backup: Always maintain a current backup of the controller application and parameter sets on an external storage medium or SD card to facilitate quick restoration in the event of hardware replacement.

• Grounding and Shielding Practice: Connect the functional earth terminal directly to the cabinet backplane with a low-impedance conductor. Ensure all communication cables are shielded to isolate the logic processor from electromagnetic interference generated by adjacent frequency inverters.
