EHDB220-21-11 ABB Bailey

EHDB220-21-11 ABB Bailey analog module

Product  Description：

• • An ABB Bailey analog module is a key component within the ABB Bailey Infi 90, Symphony DCI, and Symphony Plus control systems. These modules are specifically designed to interface with and process continuous, real-world signals from various industrial sensors and devices. They convert analog inputs (like voltage or current) into digital data that the system can use for control and monitoring, and they can also convert digital commands from the system back into analog outputs to drive field devices.



    Key Functions



    • Analog Input: These modules receive signals from sensors for parameters such as temperature, pressure, flow, or level. They filter, condition, and convert these analog signals into a digital format that the controller can interpret.

    • Analog Output: These modules take a digital value from the controller and convert it back into a proportional analog signal (typically 4-20mA or 0-10V) to control devices like valves, motor drives, or variable speed pumps.

    • Signal Isolation: Many modules provide electrical isolation to protect the system's sensitive electronics from ground loops and electrical noise originating in the field.

    • Signal Conditioning: They often include built-in circuitry to scale, filter, or linearize the input signals for accurate measurement.



    Product Parameters (Typical)



    Parameters can vary significantly based on the specific module model (e.g., IMASI03, IMCOM02, IMSET01).

    • Number of Channels: The number of input or output points per module (e.g., 8-channel input, 4-channel output).

    • Input/Output Range: The acceptable signal range (e.g., 4-20mA, 0-10V, 1-5V).

    • Resolution: The precision of the digital conversion, typically expressed in bits (e.g., 12-bit, 16-bit). Higher resolution means more accurate readings.

    • Accuracy: The maximum error of the measurement.

    • Scan Time/Update Rate: How quickly the module can process and update its signals.

    • Power Consumption: The amount of power the module draws from the system.

    • Operating Environment: The specified temperature, humidity, and vibration ranges for reliable operation.

    • Diagnostics: Features like broken wire detection, over-range/under-range detection, and module health monitoring.



    Product Advantages



    • Robust and Reliable: Built for demanding industrial environments with high resistance to electrical noise and temperature fluctuations.

    • Seamless Integration: Designed to work perfectly within the ABB Bailey control system architecture, simplifying configuration and maintenance.

    • High Accuracy: Provides precise signal conversion for critical process control loops.

    • Scalability: Allows for easy system expansion by adding more analog modules as process requirements grow.

    • Enhanced Diagnostics: Provides early warnings for wiring faults or sensor failures, improving system uptime and safety.



    Precautions



    • Compatibility: Always confirm that the specific module is compatible with your existing controller model and system software version.

    • Wiring: Follow the official wiring diagrams precisely. Incorrect wiring can lead to module damage or inaccurate readings.

    • Grounding: Proper grounding is critical for noise immunity and safe operation. Ensure the system and module are correctly grounded as per manufacturer specifications.

    • Power Management: Verify that your system's power supply can handle the load of all installed modules, especially when adding new ones.

    • ESD Protection: Handle modules with care, using proper electrostatic discharge (ESD) precautions during installation to prevent damage to sensitive electronic components.



    Product Applications



    ABB Bailey analog modules are widely used in a variety of industries where continuous process control is essential.

    • Power Generation: Used to monitor and control boiler pressure, steam temperature, and turbine speed.

    • Oil & Gas: Used to measure flow rates, tank levels, and pipeline pressures in refineries and upstream operations.

    • Pulp & Paper: Controls chemical concentrations, temperature, and pressure during the manufacturing process.

    • Chemical Processing: Manages reaction temperatures, flow rates, and levels in a safe and precise manner.

    • Water & Wastewater: Monitors and controls pump speeds, valve positions, and water quality parameters.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
