ECPP40-01 B&R

ECPP40-01 B&R Circuit Board

Product  Description：

B&R Industrial Automation, a member of the ABB Group, produces high-performance circuit boards primarily integrated into their ACOPOS drive systems, Automation PC series, and X20 I/O modules. These boards are designed for high-end machine control, characterized by their deep integration with the Automation Studio software environment and their ability to handle synchronized, multi-axis motion control with microsecond precision.

Product Parameters

The technical parameters of B&R circuit boards reflect their position in the high-speed deterministic control market:

• System Voltage: Typically operates on 24V DC for control logic, while power stages for drive boards support 200V to 480V AC.

• Processor Architecture: Often utilizes Intel Atom or ARM-based processors for high-level logic and FPGA-based processing for real-time motion tasks.

• Communication Bus: Native support for POWERLINK, a real-time Ethernet protocol with cycle times as low as 100 microseconds.

• Storage Interface: Features high-speed CFast or mSATA interfaces for robust industrial data storage and operating system hosting.

• Thermal Management: Designed for fanless operation in many configurations, utilizing advanced heat-pipe technology and high-grade thermal interfaces.

• I/O Capacity: Scalable interfaces allowing for the connection of hundreds of local or remote points via X2X Link.

Product Advantages

B&R circuit boards offer a unique set of advantages focused on flexibility and longevity:

• High-Speed Synchronicity: The specialized hardware architecture allows for perfect synchronization between sensors, controllers, and actuators, which is essential for high-speed printing and packaging.

• Modular "Slice" Design: Many B&R boards are part of a modular system where the electronics are separated from the mechanical terminal block, allowing for "permanent wiring" and easy board replacement.

• Extreme Environmental Resistance: Available in "Coated" versions (X20c) which are resistant to condensation and corrosive gases, meeting harsh industrial standards.

• Long-Term Availability: B&R is known for extended product lifecycles, often supporting and producing specific board designs for over a decade to ensure machine maintainability.

• Seamless Software Integration: The hardware is designed to be a "digital twin" of its software configuration, enabling automated firmware updates and hardware-independent application code.

Product Applications

These boards are the backbone of high-complexity automated systems:

• Adaptive Manufacturing: Powering transport systems like SuperTrak and ACOPOStrak where high-speed switching and individual shuttle control are required.

• Plastic Processing: Controlling the precise temperature and injection pressure in high-end injection molding machines.

• Packaging and Labeling: Managing high-speed motion profiles for "flying shears" and rotary cutters where timing is critical.

• Mobile Automation: Specialized boards designed with high vibration resistance for use in agricultural and construction machinery.

• Renewable Energy: Control systems for wind turbines and solar tracking arrays requiring high reliability in remote locations.

Important Precautions

To ensure the safety of the electronics and the operators, the following precautions are necessary:

• Electrostatic Discharge (ESD): B&R boards contain highly sensitive FPGA and CMOS components. Always use a grounded wrist strap when handling boards during installation or maintenance.

• Backplane Alignment: When inserting boards into an X20 or ACOPOS backplane, ensure the alignment rails are straight. Forcing a board into a misaligned slot can bend the high-density pins.

• Power Supply Quality: Use only stabilized 24V DC power supplies. Voltage spikes or significant "noise" on the power line can cause the real-time POWERLINK communication to drop or cause logic resets.

• Firmware Versioning: Ensure that the hardware revision of the board is compatible with the version of Automation Studio being used. Loading incorrect hardware configurations can lead to system-wide boot failures.

• Proper Ventilation: Although many boards are fanless, they rely on natural convection. Maintain the specified clearance distances above and below the module rack to prevent localized overheating.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
