ECE243-0 B&R

ECE243-0 B&R Central unit

Product  Description：

B&R (Bernecker + Rainer) Central Units, particularly those in the Automation PC and X20 System families, serve as the high-performance core of industrial control architectures. These units are designed to combine the robustness of a PLC with the processing power and openness of an industrial PC. By utilizing real-time operating systems and powerful Intel or ARM processors, B&R Central Units manage everything from simple logic tasks to complex motion control, robotics, and HMI visualization within a single hardware platform.

Product Parameters

The technical specifications of B&R Central Units are highly modular and vary depending on the specific series, such as the X20CP or the APC line:

• Processor Technology: Features a wide range of CPUs, from energy-efficient Intel Atom and ARM processors to high-performance Intel Core i-series (i3, i5, i7) for data-heavy applications.

• Cycle Times: Engineered for ultra-high-speed processing, with logic and motion control cycle times reaching as low as 100 microseconds.

• Memory Configuration: Equipped with high-speed DDR RAM (ranging from 512MB to 32GB) and non-volatile flash memory (CFast or SD) for OS and application storage.

• Integrated Interfaces: Standard connectivity includes multiple Gigabit Ethernet ports, USB 2.0/3.0, RS232, and integrated POWERLINK for hard real-time communication.

• Power Consumption: Optimized thermal design with low power dissipation, often allowing for fanless operation in temperatures up to 60°C.

• Real-Time Clock: High-precision internal clock with battery backup to ensure accurate timestamping for data logging and sequence of events.

Product Advantages

B&R Central Units are distinguished by their flexibility and integration capabilities within the "Integrated Automation" philosophy:

• Scalable Performance: The modular hardware allows users to swap CPU boards to increase performance without changing the application software or the I/O system.

• Maintenance-Free Design: Many units are designed without fans or rotating parts, significantly increasing reliability and reducing downtime in dusty or high-vibration environments.

• Real-Time Ethernet Integration: Native support for POWERLINK ensures perfectly synchronized motion control across hundreds of axes with sub-microsecond jitter.

• Software Uniformity: All central units are programmed using Automation Studio, allowing a single project to be deployed across different hardware classes with minimal modification.

• Future-Proof Connectivity: Built-in support for OPC UA allows the central unit to communicate directly with IT systems and cloud platforms without requiring additional gateways.

Product Applications

B&R Central Units are the preferred choice for machine builders in industries requiring high precision and complex coordination:

• Packaging Machinery: Controlling high-speed "pick and place" robots, multi-axis wrapping machines, and synchronized labeling lines.

• Plastics Industry: Managing precise temperature control and high-speed injection movements in injection molding and blow molding machines.

• Printing and Paper: Synchronizing dozens of high-speed rollers and cutting units with extreme tension control accuracy.

• Energy and Infrastructure: Serving as the main controller for wind turbines, biomass plants, and smart grid monitoring stations.

• Semiconductor Manufacturing: Providing the low-latency processing required for wafer handling and chemical vapor deposition (CVD) equipment.

Important Precautions

To ensure the long-term stability of the B&R control system, the following precautions must be observed:

• Storage Medium Protection: Never remove the CFast or SD card while the system is powered on or writing data. This can lead to file system corruption and boot failure.

• Cooling Clearances: Even fanless units require a minimum clearance (typically 30mm to 50mm) above and below the unit to allow for natural heat convection within the control cabinet.

• Firmware Compatibility: Before upgrading a CPU or replacing a module, ensure the Automation Runtime (AR) version installed on the unit is compatible with the project compiled in Automation Studio.

• Grounding and Shielding: Ensure the DIN rail is properly grounded and that all communication cables use high-quality shielding to prevent electromagnetic interference from affecting high-speed logic.

• Battery Replacement: For CPUs with a backup battery, replace the battery according to the specified maintenance interval to prevent the loss of retain variables and system time settings during power-offs.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
