AutomationDirect Processor Modules, such as those found in the Productivity series (Productivity1000, 2000, 3000) or Do-more series (BRX, H2), serve as the central intelligence hub for programmable logic controller (PLC) systems. These modules are responsible for executing the user control program, scanning inputs, solving complex logic or mathematical formulas, and updating outputs. They function as the core controller, managing communications with local I/O, remote racks, and higher-level network software.

Product Parameters

The technical capabilities of AutomationDirect Processor Modules depend on the specific series, but standard technical parameters include:

• Memory Capacity: User program memory ranging from 1MB up to 50MB, often paired with large non-volatile flash storage for data logging and documentation.

• Execution Speed: Fast processor performance featuring boolean instruction execution speeds as low as 11 nanoseconds per instruction.

• Communication Ports: Built-in multiple communication interfaces typically including dual Ethernet ports, USB programming ports, RS-232, and RS-485 serial options.

• Protocol Support: Extensive native protocol capabilities including Modbus TCP, Modbus RTU, EtherNet/IP, ASCII, and MQTT for cloud connectivity.

• Maximum I/O Capacity: Scalable architecture capable of supporting from hundreds of local I/O points to over 4000 local and remote I/O points depending on the chassis configuration.

• Programming Interface: Micro USB or Ethernet connection utilizing free, fully featured software suites like Productivity Suite or Do-more Designer.

Product Advantages

AutomationDirect Processor Modules offer several distinct benefits designed to simplify industrial automation and lower costs:

• Integrated Data Logging: Built-in microSD card slots on the processor allow for extensive data tracking, error logging, and recipe storage directly at the control level without needing a separate module.

• Display Integration: Many models feature built-in OLED or LCD character displays on the front of the processor module for quick access to diagnostic codes, system status, and user-defined messages.

• High Cost-Performance Ratio: Delivers advanced functionalities like tag-name programming and extensive communication capabilities usually found only in high-end controllers, but at an accessible price point.

• Free Programming Software: The software required to program these processors is free to download, does not require a software license or maintenance fee, and includes a full simulator.

• Tag-Name Based Programming: Replaces rigid memory addresses with descriptive text tags, making the programming, debugging, and modification of logic significantly faster and less prone to errors.

Product Applications

These processor modules are utilized across various industries for control and data acquisition:

• Conveyor and Material Handling: Coordinating sensors, motor starters, and barcode readers to route packages through logistics and distribution warehouses.

• Water and Wastewater Management: Managing pumps, level sensors, and remote telemetry units via Modbus communication in distributed water treatment systems.

• Packaging Machinery: Controlling automated wrapping, filling, capping, and labeling equipment where fast I/O scan times and precise timing are critical.

• Building Automation: Interfacing with HVAC, lighting controls, and energy tracking systems to optimize utility efficiency in commercial facilities.

• Food and Beverage Processing: Managing temperature tracking, mixing valves, and batch recipes using the built-in data logging features.

Important Precautions

To avoid hardware damage or system instability, users must strictly follow these instructions:

• Firmware Updates: Ensure all linked I/O and remote modules are compatible before updating the processor firmware. Interrupting a firmware flash can cause the module to become permanently unresponsive.

• Electrical Isolation: When connecting the processor's communication ports to external equipment powered by a different grid or source, use opto-isolators to prevent ground loops from damaging the internal communication circuits.

• MicroSD Card Handling: Never remove the microSD card while the processor is actively writing data or when the data logging LED indicator is blinking, as this can corrupt the card's file system.

• Proper Grounding: Always tie the PLC chassis grounding terminal to a low-resistance earth ground. Poor grounding causes electrical noise that can result in erratic processor resets or communication timeouts.

• Hot Swapping Restriction: Turn off the main system power before removing or inserting the processor module into the base unit chassis. Swapping a processor on a live backplane can cause electrical arcing and damage the base connector pins.
