CRI0-9063 National Instruments Programmable controller

Product  Description：

The cRIO-9063 is built on the LabVIEW RIO architecture, which integrates a Real-Time processor and a Reconfigurable I/O (RIO) FPGA. This specific model features a Zynq-7000 All Programmable SoC from Xilinx, which combines a Dual-Core ARM Cortex-A9 processor with 7-series FPGA fabric. This integration allows for high-speed data transfer between the processor and the FPGA. Because it is a 4-slot integrated system, the controller and the chassis are a single mechanical unit, which improves vibration resistance and reduces the overall system footprint.

Product Parameters

• Processor: Dual-Core ARM Cortex-A9 running at $667 \text{ MHz}$.

• Operating System: NI Linux Real-Time, providing a robust and open-source-based environment for deterministic control.

• FPGA: Xilinx Zynq-7010 containing 28,000 logic cells.

• Memory (RAM): $256 \text{ MB}$ DDR3 for data processing and application execution.

• Storage (Non-volatile): $512 \text{ MB}$ for the operating system and user data.

• Chassis Slots: 4 slots compatible with NI C Series modules.

• Network Ports: One $10/100/1000 \text{ Mbps}$ Ethernet port for high-speed connectivity.

• USB Port: One USB 2.0 Hi-Speed Host port for connecting external storage or peripherals.

• Operating Temperature Range: Standard version operates from $-20^{\circ}\text{C}$ to $55^{\circ}\text{C}$.

• Input Voltage: $9 \text{ VDC}$ to $30 \text{ VDC}$.

Product Advantages

• Integrated Design: By combining the controller and the 4-slot chassis into one unit, the cRIO-9063 offers a smaller form factor and increased mechanical reliability compared to modular controller-chassis combinations.

• Real-Time Performance: The NI Linux Real-Time OS ensures deterministic execution of tasks, which is critical for closed-loop control systems.

• FPGA Power: The onboard FPGA allows for custom hardware-timed logic, high-speed signal processing, and direct sensor interfacing with nanosecond-level timing and synchronization.

• Software Productivity: Users can program the entire system (Processor, FPGA, and I/O) using a single software tool, LabVIEW, which significantly reduces development time and complexity.

• Ruggedness: It is designed to withstand high shock (up to $50 \text{ g}$) and vibration (up to $5 \text{ g}$), making it suitable for deployment in extreme industrial settings.

Important Considerations and Precautions

• C Series Compatibility: Ensure that the C Series modules you intend to use are compatible with the cRIO-9063. Some specialized modules may have specific power or synchronization requirements.

• Thermal Management: Ensure adequate airflow around the unit. In enclosed spaces or high-temperature environments, the module's performance may be throttled if it exceeds its rated operating temperature.

• Power Supply Quality: Use a high-quality, regulated DC power supply. Industrial environments often have electrical noise; proper grounding of the chassis is essential to prevent electromagnetic interference (EMI).

• FPGA Compilation: Since the FPGA logic is custom, changes to the hardware-level code require a "compilation" process that can be time-consuming compared to standard processor-only programming.

• Linux Security: Because it runs a Linux-based OS, users should implement standard cybersecurity practices (such as changing default passwords and managing network access) if the device is connected to a public or corporate network.

Product Applications

The cRIO-9063 is highly versatile and used across many industries where compact size and high reliability are required.

• Industrial Machine Control: Controlling complex machinery that requires high-speed synchronization between motion, vision, and I/O.

• Power Grid Monitoring: Real-time analysis of power quality and phasor measurement units (PMU) for electrical substations.

• Embedded Monitoring: Long-term data logging and structural health monitoring for bridges, buildings, and large-scale industrial assets.

• Oil and Gas: Remote monitoring and control of wellheads, pipelines, and pumping stations where environmental conditions are harsh.

• Automotive Testing: On-vehicle data acquisition and control for performance testing and electronic control unit (ECU) prototyping.
