CACR-HR02BAB12Y76 YASKAWA

CACR-HR02BAB12Y76 YASKAWA controller module

Product  Description：

Yaskawa Controller Modules, specifically the MP series (Machine Controller) and the advanced iQ series modules, are the core logic and coordination units for sophisticated automation systems. These modules are designed to combine high-speed logic control with synchronized motion control in a single hardware footprint. By utilizing the proprietary MECHATROLINK networking protocol, these modules can manage dozens of axes of motion while simultaneously processing complex PLC ladder logic, making them the preferred choice for high-speed mechanical synchronization.

Product Parameters

The technical performance of a Yaskawa Controller Module is defined by its processing speed and motion control density:

• CPU Processing Speed: Optimized for rapid execution, with basic instruction processing times often reaching 10 nanoseconds or less.

• Control Cycle Time: High-speed motion updates as fast as 125 microseconds, ensuring jitter-free synchronization for high-precision motor movements.

• Axis Management Capacity: Supports a wide range of motion requirements, from 1 to 64 physical axes per module, with software capacity for hundreds of virtual axes.

• Memory Architecture: Features large-capacity non-volatile flash memory for program storage and high-speed RAM for real-time register data and motion profiles.

• Network Connectivity: Built-in MECHATROLINK-III/4 ports for motion and standard Ethernet (Modbus/TCP, EtherNet/IP) for enterprise and HMI connectivity.

• Expansion Capability: Designed to interface with a wide array of I/O, analog, and communication modules via a high-speed backplane bus.

Product Advantages

Yaskawa Controller Modules offer distinct competitive edges in the field of motion-centric automation:

• Seamless Motion Integration: Unlike standard PLCs that require external motion cards, Yaskawa modules integrate motion and logic in a single CPU, eliminating communication delays between the two.

• Highly Deterministic Performance: The dedicated motion engine ensures that axis updates are never delayed by low-priority logic tasks, maintaining perfect synchronization at all times.

• Advanced Motion Functions: Supports complex electronic camming (ECAM), electronic gearing, and high-speed registration marks out of the box.

• Reliable Industrial Design: Built without internal fans or moving parts to ensure high MTBF (Mean Time Between Failures) in environments prone to vibration and temperature fluctuations.

• Comprehensive Development Suite: Uses the MPE720 software, which provides a unified environment for programming, parameter setting, and high-speed mechanical trace monitoring.

Product Applications

These modules are the primary control choice for industries requiring extreme precision and high-speed coordination:

• Robotic Control: Acting as the main controller for delta robots, SCARA robots, and custom multi-axis gantry systems.

• Electronic Assembly: Managing high-speed component placement (Pick and Place) and high-accuracy semiconductor wafer handling.

• Packaging Machinery: Synchronizing flying shears, rotary cutters, and multi-lane labeling machines where millisecond accuracy is vital for product quality.

• Metal Processing: Controlling wire-bending machines, multi-axis spring makers, and precision laser cutting systems.

• Printing and Converting: Ensuring perfect color registration and tension control across high-speed web printing lines.

Important Precautions

To ensure the safety of the system and the longevity of the module, please follow these guidelines:

• Correct Power Sequencing: Always ensure the control power is stable before enabling the servo power. Rapidly cycling the power on the controller module can cause internal memory corruption.

• Battery Maintenance: For modules using volatile RAM for data storage, monitor the "Battery Low" indicator. Replace the lithium battery within the specified timeframe to prevent the loss of critical machine parameters.

• Grounding and Noise: The controller module must be grounded to a single point at the cabinet backplane. Use shielded cables for all MECHATROLINK and communication lines to prevent electromagnetic interference from causing "Watchdog" errors.

• Slot Installation: When installing the module into a base unit, ensure the locking mechanism is fully clicked into place. A loose connection on the backplane bus can lead to intermittent system crashes or I/O errors.

• Environment Limits: Do not install the module in areas with conductive dust, oil mist, or high humidity. If the module must operate in a harsh environment, use an appropriately rated, sealed industrial enclosure.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
