AJ65SBTC1-32DT3 MITSUBISHI

AJ65SBTC1-32DT3 MITSUBISHI Interface Module

Product  Description：

The Mitsubishi Interface Module serves as a critical bridge between Mitsubishi Electric's Programmable Logic Controllers (PLCs), such as the MELSEC iQ-R or Q Series, and external devices, networks, or peripheral hardware. These modules are engineered to facilitate seamless data exchange, ensuring that complex industrial automation systems can communicate across different protocols and physical layers.

Technical Specifications

The specifications for these modules vary depending on the specific model—such as Serial Communication, Ethernet, or CC-Link modules—but generally include the following parameters:

• Communication Protocols: Support for CC-Link IE, Modbus RTU/TCP, BACnet, and RS-232/485.

• Data Transmission Rates: High-speed processing ranging from 10 Mbps to 1 Gbps for Ethernet-based models.

• Mounting Position: Designed for standard PLC base units or remote I/O stations.

• Current Consumption: Typically optimized between 0.15A and 0.45A depending on the communication load.

• Maximum Connected Stations: Capable of managing up to 120 stations in high-end CC-Link IE configurations.

• Isolation Method: High-performance photocoupler isolation to protect internal circuitry from external surges.

Product Advantages

Mitsubishi Interface Modules are highly regarded in the automation industry for several key reasons:

Enhanced Integration They provide a unified environment where different brands of hardware can "talk" to Mitsubishi PLCs, reducing the need for complex custom gateways.

High Reliability Built to industrial-grade standards, these modules offer exceptional noise resistance and durability, ensuring 24/7 operation in harsh factory environments.

Simplified Configuration Integration with GX Works3 software allows for "parameter-based" setup. This means engineers can configure network settings through a graphical interface rather than writing extensive lines of communication code.

Advanced Diagnostics The modules feature built-in diagnostic tools that allow operators to monitor network health and pinpoint wiring or protocol errors in real-time.

Important Considerations

To ensure the longevity and performance of the module, users should adhere to the following precautions:

Power Requirements Always verify that the power supply capacity of the base unit can handle the additional current consumption of the interface module to prevent unexpected shutdowns.

Wiring and Shielding Communication cables must be kept separate from high-voltage power lines to avoid electromagnetic interference. Use only specified shielded cables for high-speed data transmission.

Firmware Compatibility Ensure that the PLC CPU firmware version is compatible with the interface module. Using a newer module with an outdated CPU may lead to "Module Error" flags.

Hot Swapping Unless explicitly stated by the specific model's manual, modules should not be removed or inserted while the PLC rack is powered on, as this can damage the internal EEPROM.

Product Applications

These modules are deployed across various sectors to streamline industrial processes:

• Automotive Manufacturing: Linking robotic assembly arms with central control units for synchronized production.

• Water Treatment Facilities: Enabling remote monitoring of pumps and sensors over long distances via Ethernet modules.

• Semiconductor Production: Facilitating high-speed data collection for quality control and precision timing.

• Building Automation: Integrating HVAC and lighting systems into a centralized PLC management system using BACnet or Modbus.
