3500/22288055-01 Bently Nevada

3500/22288055-01 Bently Nevada Servo Controller

Product  Description：

The Bently Nevada Servo Controller and Valve Driver Module is a specialized component engineered to integrate precise valve positioning with automated steam turbine control and machinery protection architectures, such as the Bently Nevada 3500 Series platform. It acts as a high-precision closed-loop driver that converts electronic command signals into current outputs to directly operate hydraulic servo valves, proportional valves, and steam admission valve actuators.

By processing continuous feedback from LVDTs (Linear Variable Differential Transformers), RVDTs, or eddy-current proximity transducers, the servo controller calculates exact mechanical positions and makes high-speed micro-adjustments. This continuous loop prevents valve hunting, ensures smooth turbine speed and load regulation, and supports automated emergency shutdown protocols to protect critical rotating assets from overspeed and mechanical failure.

Product Parameters

• Input Command Signal Ranges: 0 to 10 V DC, -10 V DC to +10 V DC, 4 to 20 mA, or digital bus communications.

• Output Current Range: Adjustable drive output up to +/- 200 mA or 0 to 1000 mA, tailored for single-coil or dual-coil servo valves.

• Feedback Sensor Compatibility: Dual or single LVDTs, RVDTs, and Bently Nevada 3300 XL proximity transducer systems.

• Position Control Accuracy: Better than +/- 0.5% of full-scale linear travel.

• Response Frequency: Up to 100 Hz dynamic frequency response for high-speed servo loop execution.

• Operating Voltage: 24 V DC system supply or standard backplane power from the 3500 rack system.

• Galvanic Isolation: 1500 V RMS isolation between signal inputs, driver outputs, field power lines, and logic backplane circuitry.

• Dither Signal Generation: Onboard adjustable dither signal frequency and amplitude to eliminate valve spool friction and stiction.

• Operating Temperature: -30°C to +65°C operational range in high-vibration power generation environments.

Product Advantages

• Precise Loop Control: Offers ultra-fast position loop processing, minimizing valve overshoot and ensuring highly stable steam flow regulation.

• Seamless System Integration: Fully compatible with Bently Nevada machinery protection racks, allowing unified monitoring of vibration, position, speed, and valve control in a single platform.

• Active Stiction Reduction: Built-in configurable dither signals keep the internal valve spool in continuous micro-motion, eliminating static friction and increasing response accuracy.

• Redundant Sensor Diagnostics: Supports dual redundant position sensors with automatic signal validation and failover logic to prevent unexpected process trips.

• High Reliability in Harsh Environments: Designed with industrial-grade electronic components to resist extreme heat, electrical noise, shock, and continuous mechanical vibration.

Important Precautions

• Correct Dither Calibration: Ensure dither frequency and amplitude are tuned according to valve manufacturer specifications to prevent premature mechanical wear on the servo valve spool.

• LVDT Phase Alignment: Verify proper phase wiring and grounding for differential feedback transducers to prevent false position feedback and control instability.

• Inductive Load Suppression: Use appropriate shielding and suppressors on output field wiring to prevent electromagnetic interference from entering adjacent sensitive vibration monitoring channels.

• Calibration During Commissioning: Perform full-stroke end-to-end position zero and span calibration after any mechanical valve maintenance or sensor replacement.

• Power Supply Quality: Maintain clean, surge-protected 24 V DC power to prevent voltage fluctuations from impacting output coil drive currents.

Product Applications

• Steam Turbine Control: Regulating main steam stop valves, governor valves, and intercept valves in power generation and combined-cycle plants.

• Gas Turbine Fuel Valve Actuation: Driving high-speed fuel metering valves and variable inlet guide vanes for gas turbine load control.

• Hydroelectric Power Generation: Controlling needle valves, wicket gates, and water flow actuators in hydro turbines.

• Process Machinery Control: Driving electro-hydraulic servo actuators in high-pressure compressors, boiler feed pumps, and heavy industrial press systems.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
