2DS100.60-1 B&R Communication Processor

Product  Description：

B&R (Bernecker + Rainer) Communication Processors are high-performance interface modules designed for the X20, X200, and APC (Automation PC) systems. These processors act as dedicated communication hubs, offloading complex networking tasks from the main CPU to ensure deterministic control and high-speed data throughput. They facilitate seamless connectivity between B&R controllers and various industrial networks, including real-time Ethernet, fieldbus systems, and cloud-based architectures.

Product Parameters

The technical characteristics of B&R Communication Processors focus on processing power and multi-protocol flexibility:

• Processor Type: Often equipped with dedicated ARM-based or specialized communication RISC processors to handle protocol stacks independently of the application logic.

• Network Support: Comprehensive compatibility with POWERLINK, openSAFETY, EtherCAT, Modbus TCP, EtherNet/IP, and PROFINET.

• Data Throughput: High-speed backplane integration allowing for internal data transfer rates reaching several hundred megabits per second.

• Interface Ports: Multiple RJ45 ports for Ethernet-based networks, often featuring integrated switches for daisy-chaining, or specialized plug-in modules for serial (RS-232/RS-485) and CAN bus.

• Buffer Memory: Significant onboard RAM and Flash memory used for large data frames, network management information, and diagnostic logging.

• Synchronization: Support for microsecond-level precision timing (IEEE 1588 PTP) essential for hard real-time motion control applications.

Product Advantages

B&R communication technology is distinguished by its modularity and performance capabilities:

• CPU Load Reduction: By processing the entire communication stack on the interface module, the main system CPU remains available for complex mathematical calculations and high-speed logic.

• Modular "Slice" Design: The X20 system architecture allows communication processors to be added or swapped easily, providing unparalleled flexibility for machine builders who export to different global markets.

• Unified Engineering: Full integration within the B&R Automation Studio software environment ensures that configuring a communication processor is a software-driven process with no need for external configuration tools.

• Advanced Safety Integration: Supports openSAFETY protocol, allowing for the transmission of safety-critical data over standard network cables without compromising SIL3/PLe certification.

• Long-Term Availability: B&R components are designed for industrial lifecycles, ensuring that communication modules remain available and compatible for decades.

Product Applications

These processors are the backbone of distributed intelligence in modern smart factories:

• High-End Motion Control: Synchronizing dozens of servo drives across a POWERLINK network for printing, textiles, or CNC machinery.

• Industrial IoT Gateways: Serving as the secure bridge between the machine floor and higher-level ERP or cloud systems via OPC UA.

• Multi-Vendor Integration: Connecting B&R control systems to third-party hardware, such as robots or specialized sensors, through a wide variety of fieldbus interfaces.

• Energy Monitoring: Collecting high-resolution power consumption data from distributed measurement modules and transmitting it to a central management unit.

• Large-Scale Infrastructure: Managing communication across vast distances in wind farms, solar arrays, or tunnel control systems where fiber optic expansion is required.

Important Precautions

To ensure maximum uptime and prevent communication failures, the following guidelines should be observed:

• Network Topology: Always adhere to the specific topology rules of the protocol in use (e.g., ring, line, or star). For POWERLINK, ensure that the number of hubs and cable lengths do not exceed the specified propagation delay limits.

• Firmware Synchronization: Ensure that the firmware version of the communication processor is compatible with the version of Automation Studio and the CPU firmware being used.

• Shielding and Grounding: Use high-quality, double-shielded S/FTP cables. Proper grounding of the DIN rail and the module's ground terminal is critical to prevent electromagnetic interference from corrupting data.

• Heat Management: When installing multiple high-performance communication processors side-by-side, verify that the cabinet's cooling system can handle the cumulative heat dissipation to prevent thermal throttling.

• Address Configuration: For fieldbus systems like CAN or Profibus, ensure that node IDs and termination resistors are correctly set. For Ethernet systems, avoid IP address conflicts by using managed switches or DHCP services where appropriate.
