25P-D017N104 Allen-Bradley

25P-D017N104 Allen-Bradley Operator unit

Product  Description：

Allen-Bradley Operator Units, primarily represented by the PanelView graphic terminal family from Rockwell Automation, serve as human-machine interfaces (HMIs) for industrial automation systems. These devices allow equipment operators to monitor, control, and interact with complex machinery and processes driven by programmable automation controllers.

By providing clear graphical representations of plant operations, real-time alarm management, trending data, and system diagnostics, Allen-Bradley operator units bridge the gap between automated logic controllers and human operators. Designed to operate reliably in harsh industrial environments, these terminals feature high-resolution displays, touchscreens or physical keypads, dynamic multi-protocol connectivity, and seamless integration into enterprise automation architectures.

Product Parameters

• Display Sizes: Ranging from 4-inch widescreen options up to 19-inch high-definition displays.

• Display Types: Active-matrix color TFT LCD displays with LED backlighting.

• Input Options: Touchscreen (analog resistive or projected capacitive) and physical keypad combinations.

• Screen Resolution: Ranging from 480 x 272 pixels on compact units up to 1920 x 1080 Full HD on high-performance models.

• Operating System: Embedded closed operating systems or Windows IoT Enterprise on open-architecture terminals.

• Onboard Memory: 512 MB to 4 GB flash memory and system RAM, expandable via SD card or USB flash drives.

• Communication Protocols: EtherNet/IP, ControlNet, DeviceNet, DH-485, and serial interfaces (RS-232, RS-422, RS-485).

• Operating Voltage: 24V DC nominal or 100V to 240V AC universal input depending on terminal chassis.

• Enclosure Protection Ratings: NEMA 4X, NEMA 12, NEMA 13, IP65, and IP66 front panel ingress protection ratings.

• Operating Temperature Range: 0°C to 55°C for standard models, with extended temperature models rated for -25°C to 70°C.

Product Advantages

• Direct Logix Integration: Native tag sharing with ControlLogix and CompactLogix controllers eliminates manual tag mapping, reducing setup time and configuration errors.

• High Environmental Durability: Rugged front bezel construction protects internal components from water jets, oil splash, dust, and corrosive industrial atmospheres.

• Enhanced Operational Visibility: High-contrast displays with wide viewing angles ensure screen clarity under diverse factory lighting conditions.

• Centralized Security and User Access: Built-in user authentication and role-based security support regulatory compliance and prevent unauthorized machine adjustments.

• Remote Monitoring Capabilities: Integrated web server functionality enables offsite monitoring and screen mirroring via secure mobile or browser interfaces.

Important Precautions

• Verify Panel Cutout and Gasket Seal: Ensure panel cutouts match exact manufacturer dimensions and tighten mounting clamps evenly to guarantee environmental sealing.

• Maintain Display Screen Cleanliness: Clean screen surfaces using non-abrasive, non-solvent solutions to prevent scratching touch coatings or degrading protective seals.

• Implement Proper Surge Protection: Install external power protection on incoming DC or AC supply lines to prevent electrical transient damage during power anomalies.

• Cable Routing and Grounding: Run Ethernet and serial communication cables separately from high-voltage AC lines, and establish proper chassis grounding to minimize electromagnetic interference.

• Backup Configuration Files: Periodically save operator runtime files and system configurations to external storage to minimize downtime during hardware replacement.

Product Applications

• Discrete Manufacturing: Monitoring assembly lines, robotic cell status, conveyor routing, and packaging machinery.

• Food and Beverage Processing: Displaying batching parameters, clean-in-place process statuses, and recipe selection screens in sanitary environments.

• Chemical and Process Industries: Controlling valve manifolds, vessel temperatures, tank levels, and safety interlocks in continuous processing plants.

• Material Handling Systems: Interface control for automated storage and retrieval systems, palletizers, and sorting equipment.

• Infrastructure and Utility Control: Real-time graphical tracking for water treatment distribution, pump stations, and energy monitoring panels.

The structure and details of the product：

Our services：

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Warranty: one year

Please make an inquiry for more models：
